InteractionLists< ParticleType > Class Template Reference

Builds direct interaction list, specifying which local (real) cells are potentially in range of each other. More...

Inheritance diagram for InteractionLists< ParticleType >:

Public Member Functions
	InteractionLists (const polyMesh &mesh)
	InteractionLists (const polyMesh &mesh, scalar maxDistance, bool writeCloud=false, const word &UName="U")
	~InteractionLists ()
void	sendReferredData (const List< DynamicList< ParticleType * >> &cellOccupancy, PstreamBuffers &pBufs)
void	receiveReferredData (PstreamBuffers &pBufs, const label startReq=0)
const polyMesh &	mesh () const
const mapDistribute &	cellMap () const
const mapDistribute &	wallFaceMap () const
const labelListList &	dil () const
const labelListList &	dwfil () const
const labelListList &	ril () const
const labelListList &	rilInverse () const
const labelListList &	rwfil () const
const labelListList &	rwfilInverse () const
const List< labelPair > &	cellIndexAndTransformToDistribute () const
const List< labelPair > &	wallFaceIndexAndTransformToDistribute () const
const List< referredWallFace > &	referredWallFaces () const
const word &	UName () const
const List< vector > &	referredWallData () const
const List< IDLList< ParticleType > > &	referredParticles () const
List< IDLList< ParticleType > > &	referredParticles ()

Detailed Description

template<class ParticleType>
class Foam::InteractionLists< ParticleType >

Builds direct interaction list, specifying which local (real) cells are potentially in range of each other.

Builds referred interaction list, specifying which cells are required to provide interactions across coupled patches (cyclic or processor). Generates referred cells, and refers particles to the correct processor, applying the appropriate transform.

Simultaneous communication and computation is possible using:

PstreamBuffers pBufs(Pstream::commsTypes::nonBlocking);
label startOfRequests = Pstream::nRequests();
il_.sendReferredData(cellOccupancy_, pBufs);
// Do other things
il_.receiveReferredData(pBufs, startOfRequests);

Requiring data:

List<DynamicList<typename CloudType::parcelType*>> cellOccupancy_;

Source files

• InteractionLists.H
• InteractionListsI.H
• InteractionLists.C
• InteractionListsIO.C

Definition at line 77 of file InteractionLists.H.

Constructor & Destructor Documentation

InteractionLists() [1/2]

InteractionLists

(

const polyMesh &

mesh

)

Definition at line 1088 of file InteractionLists.C.

InteractionLists() [2/2]

InteractionLists	(	const polyMesh &	mesh,
		scalar	maxDistance,
		bool	writeCloud = false,
		const word &	UName = "U"
	)

Definition at line 1111 of file InteractionLists.C.

~InteractionLists()

~InteractionLists

Definition at line 1142 of file InteractionLists.C.

Member Function Documentation

sendReferredData()

void sendReferredData	(	const List< DynamicList< ParticleType * >> &	cellOccupancy,
		PstreamBuffers &	pBufs
	)

Definition at line 1150 of file InteractionLists.C.

receiveReferredData()

void receiveReferredData	(	PstreamBuffers &	pBufs,
		const label	startReq = 0
	)

Definition at line 1198 of file InteractionLists.C.

mesh()

const Foam::polyMesh & mesh

inline

Definition at line 26 of file InteractionListsI.H.

cellMap()

const Foam::mapDistribute & cellMap

inline

Definition at line 34 of file InteractionListsI.H.

wallFaceMap()

const Foam::mapDistribute & wallFaceMap

inline

Definition at line 42 of file InteractionListsI.H.

dil()

const Foam::labelListList & dil

inline

Definition at line 49 of file InteractionListsI.H.

dwfil()

const Foam::labelListList & dwfil

inline

Definition at line 57 of file InteractionListsI.H.

ril()

const Foam::labelListList & ril

inline

Definition at line 64 of file InteractionListsI.H.

rilInverse()

const Foam::labelListList & rilInverse

inline

Definition at line 72 of file InteractionListsI.H.

rwfil()

const Foam::labelListList & rwfil

inline

Definition at line 79 of file InteractionListsI.H.

rwfilInverse()

const Foam::labelListList & rwfilInverse

inline

Definition at line 87 of file InteractionListsI.H.

cellIndexAndTransformToDistribute()

const Foam::List< Foam::labelPair > & cellIndexAndTransformToDistribute

inline

Definition at line 95 of file InteractionListsI.H.

wallFaceIndexAndTransformToDistribute()

const Foam::List< Foam::labelPair > & wallFaceIndexAndTransformToDistribute

inline

Definition at line 104 of file InteractionListsI.H.

referredWallFaces()

const Foam::List< Foam::referredWallFace > & referredWallFaces

inline

Definition at line 112 of file InteractionListsI.H.

UName()

const Foam::word & UName

inline

Definition at line 119 of file InteractionListsI.H.

referredWallData()

const Foam::List< Foam::vector > & referredWallData

inline

Definition at line 127 of file InteractionListsI.H.

referredParticles() [1/2]

Foam::List< Foam::IDLList< ParticleType > > & referredParticles

inline

Definition at line 135 of file InteractionListsI.H.

referredParticles() [2/2]

List<IDLList<ParticleType> >& referredParticles ( )

inline

---

The documentation for this class was generated from the following files:

• src/lagrangian/basic/InteractionLists/InteractionLists.H
• src/lagrangian/basic/InteractionLists/InteractionLists.C
• src/lagrangian/basic/InteractionLists/InteractionListsI.H
