Top level data entry class for use in dictionaries. Provides a mechanism to specify a variable as a certain type, e.g. constant or table, and provide functions to return the (interpolated) value, and integral between limits. More...

Inheritance diagram for Function1:

[legend]

Collaboration diagram for Function1:

[legend]

Public Types
typedef Type	returnType

Public Member Functions
	TypeName ("Function1") declareRunTimeSelectionTable(autoPtr

	Function1 (const word &entryName, const objectRegistry *obrPtr=nullptr)

	Function1 (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr)

	Function1 (const Function1< Type > &rhs)

virtual tmp< Function1< Type > >	clone () const =0

virtual	~Function1 ()=default

virtual bool	constant () const

virtual Type	value (const scalar x) const

virtual tmp< Field< Type > >	value (const scalarField &x) const

virtual Type	integrate (const scalar x1, const scalar x2) const

virtual tmp< Field< Type > >	integrate (const scalarField &x1, const scalarField &x2) const

virtual void	writeData (Ostream &os) const

void	writeEntries (Ostream &os) const

Static Public Member Functions
static autoPtr< Function1< Type > >	New (const word &entryName, const dictionary &dict, const word &redirectType, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)

static autoPtr< Function1< Type > >	NewCompat (const word &entryName, std::initializer_list< std::pair< const char , int >> compat, const dictionary &dict, const word &redirectType=word::null, const objectRegistry obrPtr=nullptr, const bool mandatory=true)

static autoPtr< Function1< Type > >	New (const word &entryName, const dictionary &dict, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)

static autoPtr< Function1< Type > >	NewIfPresent (const word &entryName, const dictionary &dict, const word &redirectType=word::null, const objectRegistry *obrPtr=nullptr)

static refPtr< Function1< Type > >	New (HashPtrTable< Function1< Type >> &cache, const word &entryName, const dictionary &dict, enum keyType::option matchOpt=keyType::LITERAL, const objectRegistry *obrPtr=nullptr, const bool mandatory=true)

Public Attributes
	Function1

	dictionary

const word &	entryName

const word const dictionary &	dict

const word const dictionary const objectRegistry *	obrPtr

const word const dictionary const objectRegistry	entryName

const word const dictionary const objectRegistry	dict

const word const dictionary const objectRegistry	obrPtr

Protected Member Functions
void	operator= (const Function1< Type > &)=delete

Friends
Ostream &	operator (Ostream &os, const Function1< Type > &func)

Detailed Description

Top level data entry class for use in dictionaries. Provides a mechanism to specify a variable as a certain type, e.g. constant or table, and provide functions to return the (interpolated) value, and integral between limits.

The New factory method attempts to deal with varying types of input. It accepts primitive or dictionary entries for dispatching to different function types, but wraps unspecified types as "constant".

In the dictionary form, the coefficients are the dictionary itself. This is arguably the more readable form. For example,

    <entryName>
    {
        type      linearRamp;
        start     10;
        duration  20;
    }

In the primitive form, the coefficients are provided separately. For example,

    <entryName>   linearRamp;
    <entryName>Coeffs
    {
        start     10;
        duration  20;
    }

The coeffs dictionary is optional, since it is not required by all types. For example,

    <entryName>   zero;

Source files

Definition at line 287 of file propellerInfo.H.

Member Typedef Documentation

◆ returnType

typedef Type returnType

Definition at line 117 of file Function1.H.

Constructor & Destructor Documentation

◆ Function1() [1/3]

Function1	(	const word &	entryName,
		const objectRegistry *	obrPtr = `nullptr`
	)

explicit

◆ Function1() [2/3]

Function1	(	const word &	entryName,
		const dictionary &	dict,
		const objectRegistry *	obrPtr = `nullptr`
	)

◆ Function1() [3/3]

Function1 ( const Function1< Type > & rhs )

explicit

Definition at line 53 of file Function1.C.

◆ ~Function1()

virtual ~Function1 ( )

virtualdefault

//- Selector with external storage of Function1. //- This also allows wildcard matches in a dictionary. // If the default value is used, stores an entry as "default" static refPtr<Function1<Type>> NewOrDefault ( HashPtrTable<Function1<Type>>& cache, const word& entryName, const dictionary& dict, const Type& deflt, enum keyType::option matchOpt = keyType::LITERAL, const objectRegistry* obrPtr = nullptr );

Member Function Documentation

◆ operator=()

void operator= ( const Function1< Type > & )

protecteddelete

◆ TypeName()

TypeName ( "Function1" )

◆ clone()

virtual tmp<Function1<Type> > clone ( ) const

pure virtual

◆ New() [1/3]

static autoPtr<Function1<Type> > New	(	const word &	entryName,
		const dictionary &	dict,
		const word &	redirectType,
		const objectRegistry *	obrPtr = `nullptr`,
		const bool	mandatory = `true`
	)

static

◆ NewCompat()

Foam::autoPtr< Foam::Function1< Type > > NewCompat	(	const word &	entryName,
		std::initializer_list< std::pair< const char *, int >>	compat,
		const dictionary &	dict,
		const word &	redirectType = `word::null`,
		const objectRegistry *	obrPtr = `nullptr`,
		const bool	mandatory = `true`
	)

static

Definition at line 167 of file Function1New.C.

◆ New() [2/3]

static autoPtr<Function1<Type> > New	(	const word &	entryName,
		const dictionary &	dict,
		const objectRegistry *	obrPtr = `nullptr`,
		const bool	mandatory = `true`
	)

static

◆ NewIfPresent()

Foam::autoPtr< Foam::Function1< Type > > NewIfPresent	(	const word &	entryName,
		const dictionary &	dict,
		const word &	redirectType = `word::null`,
		const objectRegistry *	obrPtr = `nullptr`
	)

static

Definition at line 205 of file Function1New.C.

Referenced by rigidBodyMotion::read().

Here is the caller graph for this function:

◆ New() [3/3]

static refPtr<Function1<Type> > New	(	HashPtrTable< Function1< Type >> &	cache,
		const word &	entryName,
		const dictionary &	dict,
		enum keyType::option	matchOpt = `keyType::LITERAL`,
		const objectRegistry *	obrPtr = `nullptr`,
		const bool	mandatory = `true`
	)

static

◆ constant()

virtual bool constant ( ) const

inlinevirtual

Definition at line 239 of file Function1.H.

◆ value() [1/2]

Type value ( const scalar x ) const

virtual

Reimplemented in FunctionObjectTrigger< Type >, Constant< Type >, FunctionObjectValue< Type >, ZeroConstant< Type >, OneConstant< Type >, CodedFunction1< Type >, Polynomial< Type >, Function1Expression< Type >, Sample< Type >, TableBase< Type >, None< Type >, stepFunction, ramp, Sine< Type >, Square< Type >, Cosine< Type >, InputValueMapper< Type >, Scale< Type >, halfCosineRamp, linearRamp, quadraticRamp, quarterCosineRamp, and quarterSineRamp.

Definition at line 62 of file Function1.C.

Referenced by solution::equationRelaxationFactor(), and solution::fieldRelaxationFactor().

Here is the caller graph for this function:

◆ value() [2/2]

Foam::tmp< Foam::Field< Type > > value ( const scalarField & x ) const

virtual

Reimplemented in Constant< Type >, OneConstant< Type >, and None< Type >.

Definition at line 71 of file Function1.C.

◆ integrate() [1/2]

Type integrate	(	const scalar	x1,
		const scalar	x2
	)		const

virtual

Reimplemented in FunctionObjectTrigger< Type >, InputValueMapper< Type >, Polynomial< Type >, Function1Expression< Type >, Constant< Type >, Sample< Type >, TableBase< Type >, FunctionObjectValue< Type >, ZeroConstant< Type >, and OneConstant< Type >.

Definition at line 81 of file Function1.C.

◆ integrate() [2/2]

Foam::tmp< Foam::Field< Type > > integrate	(	const scalarField &	x1,
		const scalarField &	x2
	)		const

virtual

Reimplemented in OneConstant< Type >.

Definition at line 90 of file Function1.C.

◆ writeData()

void writeData ( Ostream & os ) const

virtual

Reimplemented in Sine< Type >, Square< Type >, InputValueMapper< Type >, CodedFunction1< Type >, FunctionObjectTrigger< Type >, ramp, Scale< Type >, CSV< Type >, Polynomial< Type >, Function1Expression< Type >, Constant< Type >, Table< Type >, TableBase< Type >, Sample< Type >, FunctionObjectValue< Type >, TableFile< Type >, OneConstant< Type >, ZeroConstant< Type >, and None< Type >.

Definition at line 167 of file Function1.C.

Referenced by TableFile< Type >::writeData(), Sample< Type >::writeData(), TableBase< Type >::writeData(), Table< Type >::writeData(), Constant< Type >::writeData(), Polynomial< Type >::writeData(), CSV< Type >::writeData(), Scale< Type >::writeData(), ramp::writeData(), Square< Type >::writeData(), and Sine< Type >::writeData().

Here is the caller graph for this function:

◆ writeEntries()

void writeEntries ( Ostream & os ) const

Definition at line 162 of file Function1.C.

Friends And Related Function Documentation

◆ operator

Ostream& operator	(	Ostream &	os,
		const Function1< Type > &	func
	)

friend

Member Data Documentation

◆ Function1

Function1

Definition at line 126 of file Function1.H.

◆ dictionary

dictionary

Definition at line 127 of file Function1.H.

◆ entryName [1/2]

const word& entryName

Definition at line 129 of file Function1.H.

◆ dict [1/2]

const word const dictionary& dict

Definition at line 130 of file Function1.H.

◆ obrPtr [1/2]

const word const dictionary const objectRegistry* obrPtr

Definition at line 132 of file Function1.H.

◆ entryName [2/2]

const word const dictionary const objectRegistry entryName

Definition at line 133 of file Function1.H.

◆ dict [2/2]

const word const dictionary const objectRegistry dict

Definition at line 133 of file Function1.H.

◆ obrPtr [2/2]

const word const dictionary const objectRegistry obrPtr

Definition at line 134 of file Function1.H.

The documentation for this class was generated from the following files:

src/functionObjects/forces/propellerInfo/propellerInfo.H
src/OpenFOAM/primitives/functions/Function1/Function1/Function1.H
src/OpenFOAM/primitives/functions/Function1/Function1/Function1.C
src/OpenFOAM/primitives/functions/Function1/Function1/Function1New.C
