DiagTensor< Cmpt > Class Template Reference

A templated (3 x 3) diagonal tensor of objects of <T>, effectively containing 3 elements, derived from VectorSpace. More...

Inheritance diagram for DiagTensor< Cmpt >:

Collaboration diagram for DiagTensor< Cmpt >:

Public Types
enum	components { XX, YY, ZZ }
typedef DiagTensor< label >	labelType
Public Types inherited from VectorSpace< DiagTensor< Cmpt >, Cmpt, 3 >
typedef VectorSpace< Form, Cmpt, Ncmpts >	vsType
typedef Cmpt	cmptType
typedef Cmpt	magType
typedef Cmpt *	iterator

Public Member Functions
	DiagTensor ()=default
	DiagTensor (const DiagTensor &)=default
DiagTensor &	operator= (const DiagTensor &)=default
	DiagTensor (const Foam::zero)
template<class Cmpt2 >
	DiagTensor (const VectorSpace< DiagTensor< Cmpt2 >, Cmpt2, 3 > &)
	DiagTensor (const Cmpt &txx, const Cmpt &tyy, const Cmpt &tzz)
	DiagTensor (Istream &is)
const Cmpt &	xx () const
const Cmpt &	yy () const
const Cmpt &	zz () const
Cmpt &	xx ()
Cmpt &	yy ()
Cmpt &	zz ()
Public Member Functions inherited from VectorSpace< DiagTensor< Cmpt >, Cmpt, 3 >
	VectorSpace ()=default
	VectorSpace (const Foam::zero)
	VectorSpace (const VectorSpace< Form, Cmpt, Ncmpts > &vs)
	VectorSpace (const VectorSpace< Form2, Cmpt2, Ncmpts > &)
	VectorSpace (Istream &is)
const Cmpt &	component (const direction) const
Cmpt &	component (const direction)
void	component (Cmpt &, const direction) const
void	replace (const direction, const Cmpt &)
const Cmpt *	cdata () const noexcept
Cmpt *	data () noexcept
const ConstBlock< SubVector, BStart >	block () const
const Foam::VectorSpace< Form, Cmpt, Ncmpts >::template ConstBlock< SubVector, BStart >	block () const
const Cmpt &	operator[] (const direction) const
Cmpt &	operator[] (const direction)
void	operator= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator= (const Foam::zero)
void	operator+= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator-= (const VectorSpace< Form, Cmpt, Ncmpts > &)
void	operator*= (const scalar)
void	operator/= (const scalar)
iterator	begin () noexcept
const_iterator	begin () const noexcept
iterator	end () noexcept
const_iterator	end () const noexcept
const_iterator	cbegin () const noexcept
const_iterator	cend () const noexcept

Static Public Attributes
static constexpr direction	rank = 2
Static Public Attributes inherited from VectorSpace< DiagTensor< Cmpt >, Cmpt, 3 >
static constexpr direction	dim
static constexpr direction	nComponents
static constexpr direction	mRows
static constexpr direction	nCols
static const char *const	typeName
static const char *const	componentNames []
static const Form	zero
static const Form	one
static const Form	max
static const Form	min
static const Form	rootMax
static const Form	rootMin

Additional Inherited Members
Static Public Member Functions inherited from VectorSpace< DiagTensor< Cmpt >, Cmpt, 3 >
static constexpr direction	size () noexcept
static Form	uniform (const Cmpt &s)
Public Attributes inherited from VectorSpace< DiagTensor< Cmpt >, Cmpt, 3 >
const typedef Cmpt *	const_iterator
Cmpt	v_ [Ncmpts]

Detailed Description

template<class Cmpt>
class Foam::DiagTensor< Cmpt >

A templated (3 x 3) diagonal tensor of objects of <T>, effectively containing 3 elements, derived from VectorSpace.

See also

Test-DiagTensor.C

Source files

• DiagTensor.H
• DiagTensorI.H

Definition at line 52 of file DiagTensor.H.

Member Typedef Documentation

labelType

typedef DiagTensor<label> labelType

Definition at line 61 of file DiagTensor.H.

Member Enumeration Documentation

components

enum components

Enumerator
XX
YY
ZZ

Definition at line 71 of file DiagTensor.H.

Constructor & Destructor Documentation

DiagTensor() [1/6]

DiagTensor ( )

default

DiagTensor() [2/6]

DiagTensor ( const DiagTensor< Cmpt > &  )

default

DiagTensor() [3/6]

DiagTensor ( const Foam::zero  )

inline

Definition at line 28 of file DiagTensorI.H.

DiagTensor() [4/6]

DiagTensor ( const VectorSpace< DiagTensor< Cmpt2 >, Cmpt2, 3 > &  vs )

inline

Definition at line 37 of file DiagTensorI.H.

DiagTensor() [5/6]

DiagTensor ( const Cmpt &  txx, const Cmpt &  tyy, const Cmpt &  tzz  )

inline

Definition at line 47 of file DiagTensorI.H.

DiagTensor() [6/6]

DiagTensor ( Istream &  is )

inlineexplicit

Definition at line 60 of file DiagTensorI.H.

Member Function Documentation

operator=()

DiagTensor& operator= ( const DiagTensor< Cmpt > &  )

default

xx() [1/2]

Cmpt & xx

inline

Definition at line 69 of file DiagTensorI.H.

Referenced by Foam::det(), Foam::inv(), Foam::operator&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), wedgeFaPatchField< Type >::snGradTransformDiag(), wedgeFvPatchField< Type >::snGradTransformDiag(), and Foam::tr().

Here is the caller graph for this function:

yy() [1/2]

Cmpt & yy

inline

Definition at line 75 of file DiagTensorI.H.

Referenced by molecule::constantProperties::constantProperties(), Foam::det(), Foam::inv(), Foam::operator&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), wedgeFaPatchField< Type >::snGradTransformDiag(), wedgeFvPatchField< Type >::snGradTransformDiag(), and Foam::tr().

Here is the caller graph for this function:

zz() [1/2]

Cmpt & zz

inline

Definition at line 81 of file DiagTensorI.H.

Referenced by molecule::constantProperties::constantProperties(), Foam::det(), Foam::inv(), Foam::operator&(), Foam::operator+(), Foam::operator-(), Foam::operator/(), wedgeFaPatchField< Type >::snGradTransformDiag(), wedgeFvPatchField< Type >::snGradTransformDiag(), and Foam::tr().

Here is the caller graph for this function:

xx() [2/2]

Cmpt& xx ( )

inline

yy() [2/2]

Cmpt& yy ( )

inline

zz() [2/2]

Cmpt& zz ( )

inline

Member Data Documentation

rank

constexpr direction rank = 2

staticconstexpr

Definition at line 67 of file DiagTensor.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/primitives/DiagTensor/DiagTensor.H
• src/OpenFOAM/primitives/DiagTensor/DiagTensorI.H
