absolute Class Reference

Correction limiting method based on the absolute particle velocity. More...

Inheritance diagram for absolute:

Collaboration diagram for absolute:

Public Member Functions
	TypeName ("absolute")
	absolute (const dictionary &dict)
	absolute (const absolute &cl)
virtual autoPtr< CorrectionLimitingMethod >	clone () const
virtual	~absolute ()
virtual vector	limitedVelocity (const vector uP, const vector dU, const vector uMean) const
Public Member Functions inherited from CorrectionLimitingMethod
	TypeName ("correctionLimitingMethod")
	declareRunTimeSelectionTable (autoPtr, CorrectionLimitingMethod, dictionary,(const dictionary &dict),(dict))
	CorrectionLimitingMethod (const dictionary &dict)
	CorrectionLimitingMethod (const CorrectionLimitingMethod &cl)
virtual	~CorrectionLimitingMethod ()

Protected Attributes
scalar	e_

Additional Inherited Members
Static Public Member Functions inherited from CorrectionLimitingMethod
static autoPtr< CorrectionLimitingMethod >	New (const dictionary &dict)

Detailed Description

Correction limiting method based on the absolute particle velocity.

This method that limits the velocity correction to that of a rebound with a coefficient of restitution . The absolute velocity of the particle is used when calculating the magnitude of the limited correction. The direction is calculated using the relative velocity.

Source files

• absolute.H
• absolute.C

Definition at line 56 of file absolute.H.

Constructor & Destructor Documentation

absolute() [1/2]

absolute

(

const dictionary &

dict

)

Definition at line 41 of file absolute.C.

Referenced by absolute::clone().

Here is the caller graph for this function:

absolute() [2/2]

absolute

(

const absolute &

cl

)

Definition at line 48 of file absolute.C.

~absolute()

~absolute ( )

virtual

Definition at line 57 of file absolute.C.

Member Function Documentation

TypeName()

TypeName

(

"absolute"

)

clone()

virtual autoPtr<CorrectionLimitingMethod> clone ( ) const

inlinevirtual

Implements CorrectionLimitingMethod.

Definition at line 83 of file absolute.H.

References absolute::absolute().

Here is the call graph for this function:

limitedVelocity()

Foam::vector limitedVelocity ( const vector  uP, const vector  dU, const vector  uMean  ) const

virtual

Implements CorrectionLimitingMethod.

Definition at line 64 of file absolute.C.

References Foam::mag(), Foam::max(), and Foam::minMod().

Here is the call graph for this function:

Member Data Documentation

e_

scalar e_

protected

Definition at line 65 of file absolute.H.

---

The documentation for this class was generated from the following files:

• src/lagrangian/intermediate/submodels/MPPIC/CorrectionLimitingMethods/absolute/absolute.H
• src/lagrangian/intermediate/submodels/MPPIC/CorrectionLimitingMethods/absolute/absolute.C
