ConstCirculator< ContainerType > Class Template Reference

Walks over a container as if it were circular. The container must have the following members defined: More...

Inheritance diagram for ConstCirculator< ContainerType >:

Collaboration diagram for ConstCirculator< ContainerType >:

Public Types
typedef ContainerType::value_type	value_type
typedef ContainerType::size_type	size_type
typedef ContainerType::difference_type	difference_type
typedef ContainerType::const_iterator	const_iterator
typedef ContainerType::const_reference	const_reference
Public Types inherited from CirculatorBase
enum	direction { NONE, CLOCKWISE, ANTICLOCKWISE }

Public Member Functions
	ConstCirculator ()
	ConstCirculator (const ContainerType &container)
	ConstCirculator (const const_iterator &begin, const const_iterator &end)
	ConstCirculator (const ConstCirculator< ContainerType > &)
	~ConstCirculator ()
size_type	size () const
bool	circulate (const CirculatorBase::direction dir=NONE)
void	setFulcrumToIterator ()
void	setIteratorToFulcrum ()
difference_type	nRotations () const
const_reference	next () const
const_reference	prev () const
void	operator= (const ConstCirculator< ContainerType > &)
ConstCirculator< ContainerType > &	operator++ ()
ConstCirculator< ContainerType >	operator++ (int)
ConstCirculator< ContainerType > &	operator-- ()
ConstCirculator< ContainerType >	operator-- (int)
bool	operator== (const ConstCirculator< ContainerType > &c) const
bool	operator!= (const ConstCirculator< ContainerType > &c) const
const_reference	operator* () const
const_reference	operator() () const
difference_type	operator- (const ConstCirculator< ContainerType > &c) const
Public Member Functions inherited from CirculatorBase
	CirculatorBase ()

Protected Attributes
ContainerType::const_iterator	begin_
ContainerType::const_iterator	end_
ContainerType::const_iterator	iter_
ContainerType::const_iterator	fulcrum_

Detailed Description

template<class ContainerType>
class Foam::ConstCirculator< ContainerType >

Walks over a container as if it were circular. The container must have the following members defined:

• value_type
• size_type
• difference_type
• const_iterator
• const_reference

Examples:

face f(identity(5));

// Construct circulator from the face
ConstCirculator<face> circ(f);

// First check that the circulator has a size to iterate over.
// Then circulate around the list starting and finishing at the fulcrum.
if (circ.size()) do
{
    Info<< "Iterate forwards over face : " << circ() << endl;

} while (circ.circulate(CirculatorBase::CLOCKWISE));

face f(identity(5));

ConstCirculator<face> circClockwise(f);
ConstCirculator<face> circAnticlockwise(f);

if (circClockwise.size() && circAnticlockwise.size()) do
{
    Info<< "Iterate forward over face :" << circClockwise() << endl;
    Info<< "Iterate backward over face:" << circAnticlockwise() << endl;
}
while
(
    circClockwise.circulate(CirculatorBase::CLOCKWISE),
    circAnticlockwise.circulate(CirculatorBase::ANTICLOCKWISE)
);

Source files

• ConstCirculator.H
• ConstCirculatorI.H

Definition at line 89 of file ConstCirculator.H.

Member Typedef Documentation

value_type

typedef ContainerType::value_type value_type

Definition at line 118 of file ConstCirculator.H.

size_type

typedef ContainerType::size_type size_type

Definition at line 121 of file ConstCirculator.H.

difference_type

typedef ContainerType::difference_type difference_type

Definition at line 125 of file ConstCirculator.H.

const_iterator

typedef ContainerType::const_iterator const_iterator

Definition at line 128 of file ConstCirculator.H.

const_reference

typedef ContainerType::const_reference const_reference

Definition at line 132 of file ConstCirculator.H.

Constructor & Destructor Documentation

ConstCirculator() [1/4]

ConstCirculator

inline

Definition at line 27 of file ConstCirculatorI.H.

ConstCirculator() [2/4]

ConstCirculator ( const ContainerType &  container )

inlineexplicit

Definition at line 39 of file ConstCirculatorI.H.

ConstCirculator() [3/4]

ConstCirculator ( const const_iterator &  begin, const const_iterator &  end  )

inline

Definition at line 53 of file ConstCirculatorI.H.

ConstCirculator() [4/4]

ConstCirculator ( const ConstCirculator< ContainerType > &  rhs )

inline

Definition at line 68 of file ConstCirculatorI.H.

~ConstCirculator()

~ConstCirculator

Definition at line 83 of file ConstCirculatorI.H.

Member Function Documentation

size()

Foam::ConstCirculator< ContainerType >::size_type size

inline

Definition at line 91 of file ConstCirculatorI.H.

circulate()

bool circulate ( const CirculatorBase::direction  dir = NONE )

inline

Definition at line 99 of file ConstCirculatorI.H.

References CirculatorBase::ANTICLOCKWISE, and CirculatorBase::CLOCKWISE.

Referenced by face::compare(), and processorPolyPatch::matchFace().

Here is the caller graph for this function:

setFulcrumToIterator()

void setFulcrumToIterator

inline

Definition at line 117 of file ConstCirculatorI.H.

Referenced by face::compare(), and processorPolyPatch::matchFace().

Here is the caller graph for this function:

setIteratorToFulcrum()

void setIteratorToFulcrum

inline

Definition at line 124 of file ConstCirculatorI.H.

Referenced by face::compare(), and processorPolyPatch::matchFace().

Here is the caller graph for this function:

nRotations()

Foam::ConstCirculator< ContainerType >::difference_type nRotations

inline

Definition at line 132 of file ConstCirculatorI.H.

Referenced by processorPolyPatch::matchFace().

Here is the caller graph for this function:

next()

Foam::ConstCirculator< ContainerType >::const_reference next

inline

Definition at line 140 of file ConstCirculatorI.H.

prev()

Foam::ConstCirculator< ContainerType >::const_reference prev

inline

Definition at line 153 of file ConstCirculatorI.H.

operator=()

void operator= ( const ConstCirculator< ContainerType > &  rhs )

inline

Definition at line 168 of file ConstCirculatorI.H.

References ConstCirculator< ContainerType >::begin_, ConstCirculator< ContainerType >::end_, ConstCirculator< ContainerType >::fulcrum_, and ConstCirculator< ContainerType >::iter_.

operator++() [1/2]

Foam::ConstCirculator< ContainerType > & operator++

inline

Definition at line 186 of file ConstCirculatorI.H.

operator++() [2/2]

Foam::ConstCirculator< ContainerType > operator++ ( int  )

inline

Definition at line 200 of file ConstCirculatorI.H.

operator--() [1/2]

Foam::ConstCirculator< ContainerType > & operator--

inline

Definition at line 210 of file ConstCirculatorI.H.

operator--() [2/2]

Foam::ConstCirculator< ContainerType > operator-- ( int  )

inline

Definition at line 224 of file ConstCirculatorI.H.

operator==()

bool operator== ( const ConstCirculator< ContainerType > &  c ) const

inline

Definition at line 234 of file ConstCirculatorI.H.

References Foam::constant::universal::c.

operator!=()

bool operator!= ( const ConstCirculator< ContainerType > &  c ) const

inline

Definition at line 250 of file ConstCirculatorI.H.

References Foam::constant::universal::c.

operator*()

Foam::ConstCirculator< ContainerType >::const_reference operator*

inline

Definition at line 260 of file ConstCirculatorI.H.

operator()()

Foam::ConstCirculator< ContainerType >::const_reference operator()

inline

Definition at line 268 of file ConstCirculatorI.H.

References Foam::operator*().

Here is the call graph for this function:

operator-()

Foam::ConstCirculator< ContainerType >::difference_type operator- ( const ConstCirculator< ContainerType > &  c ) const

inline

Definition at line 277 of file ConstCirculatorI.H.

References Foam::constant::universal::c.

Member Data Documentation

begin_

ContainerType::const_iterator begin_

protected

Definition at line 99 of file ConstCirculator.H.

Referenced by ConstCirculator< ContainerType >::operator=().

end_

ContainerType::const_iterator end_

protected

Definition at line 102 of file ConstCirculator.H.

Referenced by ConstCirculator< ContainerType >::operator=().

iter_

ContainerType::const_iterator iter_

protected

Definition at line 105 of file ConstCirculator.H.

Referenced by ConstCirculator< ContainerType >::operator=().

fulcrum_

ContainerType::const_iterator fulcrum_

protected

Definition at line 110 of file ConstCirculator.H.

Referenced by ConstCirculator< ContainerType >::operator=().

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/containers/Circulators/ConstCirculator/ConstCirculator.H
• src/OpenFOAM/containers/Circulators/ConstCirculator/ConstCirculatorI.H
