CollidingParcel Class Reference

Wrapper around kinematic parcel types to add collision modelling. More...

Collaboration diagram for CollidingParcel:

Classes
class	constantProperties
class	iNew

Public Types
typedef ParcelType::trackingData	trackingData

Public Member Functions
	TypeName ("CollidingParcel")
	AddToPropertyList (ParcelType, " (fx fy fz)"+" (angularMomentumx angularMomentumy angularMomentumz)"+" (torquex torquey torquez)"+" collisionRecordsPairAccessed"+" collisionRecordsPairOrigProcOfOther"+" collisionRecordsPairOrigIdOfOther"+" (collisionRecordsPairData)"+" collisionRecordsWallAccessed"+" collisionRecordsWallPRel"+" (collisionRecordsWallData)")
	CollidingParcel (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti)
	CollidingParcel (const polyMesh &mesh, const vector &position, const label celli)
	CollidingParcel (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti, const label typeId, const scalar nParticle0, const scalar d0, const scalar dTarget0, const vector &U0, const vector &f0, const vector &angularMomentum0, const vector &torque0, const typename ParcelType::constantProperties &constProps)
	CollidingParcel (const polyMesh &mesh, Istream &is, bool readFields=true, bool newFormat=true)
	CollidingParcel (const CollidingParcel &p)
	CollidingParcel (const CollidingParcel &p, const polyMesh &mesh)
virtual autoPtr< particle >	clone () const
virtual autoPtr< particle >	clone (const polyMesh &mesh) const
const vector &	f () const
const vector &	angularMomentum () const
const vector &	torque () const
const collisionRecordList &	collisionRecords () const
vector &	f ()
vector &	angularMomentum ()
vector &	torque ()
collisionRecordList &	collisionRecords ()
vector	omega () const
template<class TrackCloudType >
bool	move (TrackCloudType &cloud, trackingData &td, const scalar trackTime)
virtual void	transformProperties (const tensor &T)
virtual void	transformProperties (const vector &separation)
void	writeProperties (Ostream &os, const wordRes &filters, const word &delim, const bool namesOnly) const

Static Public Member Functions
template<class CloudType >
static void	readFields (CloudType &c)
template<class CloudType >
static void	writeFields (const CloudType &c)
template<class CloudType >
static void	readObjects (CloudType &c, const objectRegistry &obr)
template<class CloudType >
static void	writeObjects (const CloudType &c, objectRegistry &obr)

Static Public Attributes
static const std::size_t	sizeofFields

Protected Attributes
vector	f_
vector	angularMomentum_
vector	torque_
collisionRecordList	collisionRecords_

Friends
Ostream &	operator (Ostream &, const CollidingParcel< ParcelType > &)

Detailed Description

Wrapper around kinematic parcel types to add collision modelling.

Source files

• CollidingParcel.H
• CollidingParcelI.H
• CollidingParcel.C
• CollidingParcelIO.C

Definition at line 57 of file CollidingParcel.H.

Member Typedef Documentation

trackingData

typedef ParcelType::trackingData trackingData

Definition at line 123 of file CollidingParcel.H.

Constructor & Destructor Documentation

CollidingParcel() [1/6]

CollidingParcel ( const polyMesh &  mesh, const barycentric &  coordinates, const label  celli, const label  tetFacei, const label  tetPti  )

inline

Referenced by CollidingParcel::clone().

Here is the caller graph for this function:

CollidingParcel() [2/6]

CollidingParcel ( const polyMesh &  mesh, const vector &  position, const label  celli  )

inline

CollidingParcel() [3/6]

CollidingParcel ( const polyMesh &  mesh, const barycentric &  coordinates, const label  celli, const label  tetFacei, const label  tetPti, const label  typeId, const scalar  nParticle0, const scalar  d0, const scalar  dTarget0, const vector &  U0, const vector &  f0, const vector &  angularMomentum0, const vector &  torque0, const typename ParcelType::constantProperties &  constProps  )

inline

CollidingParcel() [4/6]

CollidingParcel	(	const polyMesh &	mesh,
		Istream &	is,
		bool	readFields = true,
		bool	newFormat = true
	)

CollidingParcel() [5/6]

CollidingParcel

(

const CollidingParcel &

p

)

CollidingParcel() [6/6]

CollidingParcel	(	const CollidingParcel &	p,
		const polyMesh &	mesh
	)

Member Function Documentation

TypeName()

TypeName

(

"CollidingParcel"

)

AddToPropertyList()

AddToPropertyList	(	ParcelType	,
		" (fx fy fz)"+" (angularMomentumx angularMomentumy angularMomentumz)"+" (torquex torquey torquez)"+" collisionRecordsPairAccessed"+" collisionRecordsPairOrigProcOfOther"+" collisionRecordsPairOrigIdOfOther"+" (collisionRecordsPairData)"+" collisionRecordsWallAccessed"+" collisionRecordsWallPRel"+" (collisionRecordsWallData)"
	)

clone() [1/2]

virtual autoPtr<particle> clone ( ) const

inlinevirtual

Definition at line 225 of file CollidingParcel.H.

References CollidingParcel::CollidingParcel().

Here is the call graph for this function:

clone() [2/2]

virtual autoPtr<particle> clone ( const polyMesh &  mesh ) const

inlinevirtual

Definition at line 231 of file CollidingParcel.H.

References CollidingParcel::CollidingParcel(), and mesh.

Here is the call graph for this function:

f() [1/2]

const Foam::vector & f ( ) const

inline

Definition at line 152 of file CollidingParcelI.H.

References CollidingParcel::f_.

angularMomentum() [1/2]

const Foam::vector & angularMomentum ( ) const

inline

Definition at line 160 of file CollidingParcelI.H.

References CollidingParcel::angularMomentum_.

torque() [1/2]

const Foam::vector & torque ( ) const

inline

Definition at line 167 of file CollidingParcelI.H.

References CollidingParcel::torque_.

collisionRecords() [1/2]

const Foam::collisionRecordList & collisionRecords ( ) const

inline

Definition at line 175 of file CollidingParcelI.H.

References CollidingParcel::collisionRecords_.

f() [2/2]

Foam::vector & f ( )

inline

Definition at line 182 of file CollidingParcelI.H.

References CollidingParcel::f_.

angularMomentum() [2/2]

Foam::vector & angularMomentum ( )

inline

Definition at line 189 of file CollidingParcelI.H.

References CollidingParcel::angularMomentum_.

torque() [2/2]

Foam::vector & torque ( )

inline

Definition at line 196 of file CollidingParcelI.H.

References CollidingParcel::torque_.

collisionRecords() [2/2]

Foam::collisionRecordList & collisionRecords ( )

inline

Definition at line 204 of file CollidingParcelI.H.

References CollidingParcel::collisionRecords_.

omega()

Foam::vector omega ( ) const

inline

Definition at line 211 of file CollidingParcelI.H.

References CollidingParcel::angularMomentum_.

move()

bool move	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	trackTime
	)

Definition at line 59 of file CollidingParcel.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, NotImplemented, and p.

Here is the call graph for this function:

transformProperties() [1/2]

void transformProperties ( const tensor &  T )

virtual

Definition at line 115 of file CollidingParcel.C.

References T, and Foam::transform().

Here is the call graph for this function:

transformProperties() [2/2]

void transformProperties ( const vector &  separation )

virtual

Definition at line 129 of file CollidingParcel.C.

readFields()

void readFields ( CloudType &  c )

static

Definition at line 91 of file CollidingParcelIO.C.

References Foam::constant::universal::c, f(), IOobject::MUST_READ, p, and Foam::readFields().

Here is the call graph for this function:

writeFields()

void writeFields ( const CloudType &  c )

static

Definition at line 197 of file CollidingParcelIO.C.

References Foam::constant::universal::c, f(), IOobject::NO_READ, p, and Foam::writeFields().

Here is the call graph for this function:

writeProperties()

void writeProperties	(	Ostream &	os,
		const wordRes &	filters,
		const word &	delim,
		const bool	namesOnly
	)		const

Definition at line 289 of file CollidingParcelIO.C.

References os(), and writeProp.

Here is the call graph for this function:

readObjects()

void readObjects ( CloudType &  c, const objectRegistry &  obr  )

static

Definition at line 314 of file CollidingParcelIO.C.

References Foam::constant::universal::c, f(), and p.

Here is the call graph for this function:

writeObjects()

void writeObjects ( const CloudType &  c, objectRegistry &  obr  )

static

Definition at line 342 of file CollidingParcelIO.C.

References Foam::constant::universal::c, f(), and p.

Here is the call graph for this function:

Friends And Related Function Documentation

operator

Ostream& operator ( Ostream &  , const CollidingParcel< ParcelType > &    )

friend

Member Data Documentation

sizeofFields

const std::size_t sizeofFields

static

Definition at line 80 of file CollidingParcel.H.

f_

vector f_

protected

Definition at line 131 of file CollidingParcel.H.

Referenced by CollidingParcel::f().

angularMomentum_

vector angularMomentum_

protected

Definition at line 134 of file CollidingParcel.H.

Referenced by CollidingParcel::angularMomentum(), and CollidingParcel::omega().

torque_

vector torque_

protected

Definition at line 138 of file CollidingParcel.H.

Referenced by CollidingParcel::torque().

collisionRecords_

collisionRecordList collisionRecords_

protected

Definition at line 141 of file CollidingParcel.H.

Referenced by CollidingParcel::collisionRecords().

---

The documentation for this class was generated from the following files:

• src/lagrangian/intermediate/parcels/Templates/CollidingParcel/CollidingParcel.H
• src/lagrangian/intermediate/parcels/Templates/CollidingParcel/CollidingParcel.C
• src/lagrangian/intermediate/parcels/Templates/CollidingParcel/CollidingParcelI.H
• src/lagrangian/intermediate/parcels/Templates/CollidingParcel/CollidingParcelIO.C
