Public Member Functions | List of all members
CoBlended< Type > Class Template Reference
Numerics » Finite volume numerical schemes » Surface interpolation schemes

Two-scheme Courant number based blending differencing scheme. More...

Inheritance diagram for CoBlended< Type >:
Inheritance graph
[legend]
Collaboration diagram for CoBlended< Type >:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("CoBlended")

 CoBlended (const fvMesh &mesh, Istream &is)

 CoBlended (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &is)

virtual tmp< surfaceScalarField > blendingFactor (const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< surfaceScalarField > weights (const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &vf) const

virtual bool corrected () const

virtual tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > correction (const GeometricField< Type, fvPatchField, volMesh > &vf) const

- Public Member Functions inherited from surfaceInterpolationScheme< Type >
 TypeName ("surfaceInterpolationScheme")

 declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, Mesh,(const fvMesh &mesh, Istream &schemeData),(mesh, schemeData))

 declareRunTimeSelectionTable (tmp, surfaceInterpolationScheme, MeshFlux,(const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData),(mesh, faceFlux, schemeData))

 surfaceInterpolationScheme (const fvMesh &mesh)

virtual ~surfaceInterpolationScheme ()=default

const fvMesh & mesh () const

virtual tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const surfaceVectorField &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf) const

tmp< GeometricField< typename innerProduct< vector, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const surfaceVectorField &Sf, const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const tmp< GeometricField< Type, fvPatchField, volMesh >> &) const

- Public Member Functions inherited from refCount
constexpr refCount () noexcept

int count () const noexcept

bool unique () const noexcept

void operator++ () noexcept

void operator++ (int) noexcept

void operator-- () noexcept

void operator-- (int) noexcept

- Public Member Functions inherited from blendedSchemeBase< Type >
 blendedSchemeBase ()

virtual ~blendedSchemeBase ()=default


Additional Inherited Members

- Static Public Member Functions inherited from surfaceInterpolationScheme< Type >
static tmp< surfaceInterpolationScheme< Type > > New (const fvMesh &mesh, Istream &schemeData)

static tmp< surfaceInterpolationScheme< Type > > New (const fvMesh &mesh, const surfaceScalarField &faceFlux, Istream &schemeData)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &, const tmp< surfaceScalarField > &)

template<class SFType >
static tmp< GeometricField< typename innerProduct< typename SFType::value_type, Type >::type, fvsPatchField, surfaceMesh > > dotInterpolate (const SFType &Sf, const GeometricField< Type, fvPatchField, volMesh > &vf, const tmp< surfaceScalarField > &tlambdas)

static tmp< GeometricField< Type, fvsPatchField, surfaceMesh > > interpolate (const GeometricField< Type, fvPatchField, volMesh > &, const tmp< surfaceScalarField > &)


Detailed Description

template<class Type>
class Foam::CoBlended< Type >

Two-scheme Courant number based blending differencing scheme.

Similar to localBlended but uses a blending factor computed from the face-based Courant number and the lower and upper Courant number limits supplied:

\[ weight = 1 - max(min((Co - Co1)/(Co2 - Co1), 1), 0) \]

where

$ Co1 $ = Courant number below which scheme1 is used
$ Co2 $ = Courant number above which scheme2 is used

The weight applies to the first scheme and 1-weight to the second scheme.

Usage
Example of the CoBlended scheme specification using LUST for Courant numbers less than 1 and linearUpwind for Courant numbers greater than 10:
divSchemes
{
    .
    .
    div(phi,U)      Gauss CoBlended 1 LUST grad(U) 10 linearUpwind grad(U);
    .
    .
}
Source files

Definition at line 88 of file CoBlended.H.

Constructor & Destructor Documentation

◆ CoBlended() [1/2]

CoBlended ( const fvMesh &  mesh,
Istream &  is
)
inline

Definition at line 132 of file CoBlended.H.

References Foam::exit(), Foam::FatalIOError, and FatalIOErrorInFunction.

Here is the call graph for this function:

◆ CoBlended() [2/2]

CoBlended ( const fvMesh &  mesh,
const surfaceScalarField &  faceFlux,
Istream &  is
)
inline

Definition at line 165 of file CoBlended.H.

References Foam::exit(), Foam::FatalIOError, and FatalIOErrorInFunction.

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "CoBlended< Type >"  )

◆ blendingFactor()

virtual tmp<surfaceScalarField> blendingFactor ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Implements blendedSchemeBase< Type >.

Definition at line 198 of file CoBlended.H.

References surfaceInterpolation::deltaCoeffs(), TimeState::deltaT(), Foam::dimArea, Foam::dimDensity, Foam::dimVelocity, Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::fvc::interpolate(), Foam::mag(), fvMesh::magSf(), Foam::max(), surfaceInterpolationScheme< Type >::mesh(), Foam::min(), rho, and fvMesh::time().

Referenced by CoBlended< Type >::correction(), CoBlended< Type >::interpolate(), and CoBlended< Type >::weights().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ weights()

tmp<surfaceScalarField> weights ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Implements surfaceInterpolationScheme< Type >.

Definition at line 249 of file CoBlended.H.

References CoBlended< Type >::blendingFactor().

Here is the call graph for this function:

◆ interpolate()

tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > interpolate ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 265 of file CoBlended.H.

References CoBlended< Type >::blendingFactor().

Here is the call graph for this function:

◆ corrected()

virtual bool corrected ( ) const
inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 278 of file CoBlended.H.

Referenced by CoBlended< Type >::correction().

Here is the caller graph for this function:

◆ correction()

virtual tmp<GeometricField<Type, fvsPatchField, surfaceMesh> > correction ( const GeometricField< Type, fvPatchField, volMesh > &  vf) const
inlinevirtual

Reimplemented from surfaceInterpolationScheme< Type >.

Definition at line 288 of file CoBlended.H.

References CoBlended< Type >::blendingFactor(), and CoBlended< Type >::corrected().

Here is the call graph for this function:
The documentation for this class was generated from the following file:
