This boundary condition provides a base class for 'mixed' type boundary conditions, i.e. conditions that mix fixed value and patch-normal gradient conditions. More...

Inheritance diagram for mixedFvPatchField< Type >:

[legend]

Collaboration diagram for mixedFvPatchField< Type >:

[legend]

Public Member Functions
	TypeName ("mixed")
	Runtime type information. More...

	mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)
	Construct from patch and internal field. More...

	mixedFvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	mixedFvPatchField (const mixedFvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping the given mixedFvPatchField onto a new patch. More...

	mixedFvPatchField (const mixedFvPatchField< Type > &)
	Construct as copy. More...

virtual tmp< fvPatchField< Type > >	clone () const
	Construct and return a clone. More...

	mixedFvPatchField (const mixedFvPatchField< Type > &, const DimensionedField< Type, volMesh > &)
	Construct as copy setting internal field reference. More...

virtual tmp< fvPatchField< Type > >	clone (const DimensionedField< Type, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual bool	fixesValue () const
	Return true if this patch field fixes a value. More...

virtual Field< Type > &	refValue ()

virtual const Field< Type > &	refValue () const

virtual Field< Type > &	refGrad ()

virtual const Field< Type > &	refGrad () const

virtual scalarField &	valueFraction ()

virtual const scalarField &	valueFraction () const

virtual void	autoMap (const fvPatchFieldMapper &)
	Map (and resize as needed) from self given a mapping object. More...

virtual void	rmap (const fvPatchField< Type > &, const labelList &)
	Reverse map the given fvPatchField onto this fvPatchField. More...

virtual tmp< Field< Type > >	snGrad () const
	Return gradient at boundary. More...

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::blocking)
	Evaluate the patch field. More...

virtual tmp< Field< Type > >	valueInternalCoeffs (const tmp< scalarField > &) const
	Return the matrix diagonal coefficients corresponding to the. More...

virtual tmp< Field< Type > >	valueBoundaryCoeffs (const tmp< scalarField > &) const
	Return the matrix source coefficients corresponding to the. More...

virtual tmp< Field< Type > >	gradientInternalCoeffs () const
	Return the matrix diagonal coefficients corresponding to the. More...

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const
	Return the matrix source coefficients corresponding to the. More...

virtual void	write (Ostream &) const
	Write. More...

virtual void	operator= (const UList< Type > &)

virtual void	operator= (const fvPatchField< Type > &)

virtual void	operator+= (const fvPatchField< Type > &)

virtual void	operator-= (const fvPatchField< Type > &)

virtual void	operator*= (const fvPatchField< scalar > &)

virtual void	operator/= (const fvPatchField< scalar > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const Type &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const scalar)

Public Member Functions inherited from fvPatchField< Type >
	TypeName ("fvPatchField")
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, fvPatchField, patch,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (tmp, fvPatchField, patchMapper,(const fvPatchField< Type > &ptf, const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const fvPatchFieldMapper &m),(dynamic_cast< const fvPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (tmp, fvPatchField, dictionary,(const fvPatch &p, const DimensionedField< Type, volMesh > &iF, const dictionary &dict),(p, iF, dict))

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &)
	Construct from patch and internal field. More...

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const word &patchType)
	Construct from patch and internal field and patch type. More...

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const Field< Type > &)
	Construct from patch and internal field and patch field. More...

	fvPatchField (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &, const bool valueRequired=false)
	Construct from patch, internal field and dictionary. More...

	fvPatchField (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping the given fvPatchField onto a new patch. More...

	fvPatchField (const fvPatchField< Type > &)
	Construct as copy. More...

	fvPatchField (const fvPatchField< Type > &, const DimensionedField< Type, volMesh > &)
	Construct as copy setting internal field reference. More...

virtual tmp< fvPatchField< Type > >	clone () const
	Construct and return a clone. More...

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatch &p)

Foam::tmp< Foam::fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &pf)

virtual	~fvPatchField ()
	Destructor. More...

const objectRegistry &	db () const
	Return local objectRegistry. More...

const fvPatch &	patch () const
	Return patch. More...

const DimensionedField< Type, volMesh > &	dimensionedInternalField () const
	Return dimensioned internal field reference. More...

const Field< Type > &	internalField () const
	Return internal field reference. More...

const word &	patchType () const
	Optional patch type. More...

word &	patchType ()
	Optional patch type. More...

virtual bool	fixesValue () const
	Return true if this patch field fixes a value. More...

virtual bool	coupled () const
	Return true if this patch field is coupled. More...

bool	updated () const
	Return true if the boundary condition has already been updated. More...

bool	manipulatedMatrix () const
	Return true if the matrix has already been manipulated. More...

virtual tmp< Field< Type > >	snGrad () const
	Return patch-normal gradient. More...

virtual tmp< Field< Type > >	snGrad (const scalarField &deltaCoeffs) const
	Return patch-normal gradient for coupled-patches. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	updateCoeffs (const scalarField &weights)
	Update the coefficients associated with the patch field. More...

virtual tmp< Field< Type > >	patchInternalField () const
	Return internal field next to patch as patch field. More...

virtual void	patchInternalField (Field< Type > &) const
	Return internal field next to patch as patch field. More...

virtual tmp< Field< Type > >	patchNeighbourField () const
	Return patchField on the opposite patch of a coupled patch. More...

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::blocking)
	Initialise the evaluation of the patch field. More...

virtual tmp< Field< Type > >	gradientInternalCoeffs () const
	Return the matrix diagonal coefficients corresponding to the. More...

virtual tmp< Field< Type > >	gradientInternalCoeffs (const scalarField &deltaCoeffs) const
	Return the matrix diagonal coefficients corresponding to the. More...

virtual tmp< Field< Type > >	gradientBoundaryCoeffs () const
	Return the matrix source coefficients corresponding to the. More...

virtual tmp< Field< Type > >	gradientBoundaryCoeffs (const scalarField &deltaCoeffs) const
	Return the matrix source coefficients corresponding to the. More...

virtual void	manipulateMatrix (fvMatrix< Type > &matrix)
	Manipulate matrix. More...

virtual void	manipulateMatrix (fvMatrix< Type > &matrix, const scalarField &weights)
	Manipulate matrix with given weights. More...

void	writeEntryIfDifferent (Ostream &os, const word &entryName, const EntryType &value1, const EntryType &value2) const
	Helper function to write the keyword and entry only if the. More...

void	check (const fvPatchField< Type > &) const
	Check fvPatchField<Type> against given fvPatchField<Type> More...

virtual void	operator== (const fvPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

Private Attributes
Field< Type >	refValue_
	Value field. More...

Field< Type >	refGrad_
	Normal gradient field. More...

scalarField	valueFraction_
	Fraction (0-1) of value used for boundary condition. More...

Additional Inherited Members
Public Types inherited from fvPatchField< Type >
typedef fvPatch	Patch

Static Public Member Functions inherited from fvPatchField< Type >
static tmp< fvPatchField< Type > >	New (const word &, const fvPatch &, const DimensionedField< Type, volMesh > &)
	Return a pointer to a new patchField created on freestore given. More...

static tmp< fvPatchField< Type > >	New (const word &, const word &actualPatchType, const fvPatch &, const DimensionedField< Type, volMesh > &)
	Return a pointer to a new patchField created on freestore given. More...

static tmp< fvPatchField< Type > >	New (const fvPatchField< Type > &, const fvPatch &, const DimensionedField< Type, volMesh > &, const fvPatchFieldMapper &)
	Return a pointer to a new patchField created on freestore from. More...

static tmp< fvPatchField< Type > >	New (const fvPatch &, const DimensionedField< Type, volMesh > &, const dictionary &)
	Return a pointer to a new patchField created on freestore. More...

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatch &)
	Return a pointer to a new calculatedFvPatchField created on. More...

static tmp< fvPatchField< Type > >	NewCalculatedType (const fvPatchField< Type2 > &)
	Return a pointer to a new calculatedFvPatchField created on. More...

static const word &	calculatedType ()
	Return the type of the calculated for of fvPatchField. More...

Static Public Attributes inherited from fvPatchField< Type >
static int	disallowGenericFvPatchField
	Debug switch to disallow the use of genericFvPatchField. More...

Detailed Description

template<class Type>
class Foam::mixedFvPatchField< Type >

This boundary condition provides a base class for 'mixed' type boundary conditions, i.e. conditions that mix fixed value and patch-normal gradient conditions.

The respective contributions from each is determined by a weight field:

$x_p = w x_p + (1-w) \left(x_c + \frac{\nabla_\perp x}{\Delta}\right)$

where

	=	patch values
	=	patch internal cell values
	=	weight field
$\Delta$	=	inverse distance from face centre to internal cell centre
	=	weighting (0-1)

Patch usage

Property	Description	Required
`valueFraction`	weight field	yes
`refValue`	fixed value	yes
`refGrad`	patch normal gradient	yes

Note: This condition is not usually applied directly; instead, use a derived mixed condition such as inletOutlet

See also: Foam::inletOutletFvPatchField

Source files

Definition at line 126 of file mixedFvPatchField.H.

Constructor & Destructor Documentation

◆ mixedFvPatchField() [1/5]

mixedFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 37 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [2/5]

mixedFvPatchField	(	const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 77 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [3/5]

mixedFvPatchField	(	const mixedFvPatchField< Type > &	ptf,
		const fvPatch &	p,
		const DimensionedField< Type, volMesh > &	iF,
		const fvPatchFieldMapper &	mapper
	)

Construct by mapping the given mixedFvPatchField onto a new patch.

Definition at line 51 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [4/5]

mixedFvPatchField ( const mixedFvPatchField< Type > & ptf )

Construct as copy.

Definition at line 94 of file mixedFvPatchField.C.

◆ mixedFvPatchField() [5/5]

mixedFvPatchField	(	const mixedFvPatchField< Type > &	ptf,
		const DimensionedField< Type, volMesh > &	iF
	)

Construct as copy setting internal field reference.

Definition at line 107 of file mixedFvPatchField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "mixed" )

Runtime type information.

◆ clone() [1/2]

virtual tmp<fvPatchField<Type> > clone ( ) const

inlinevirtual

Construct and return a clone.

Reimplemented in codedMixedFvPatchField< Type >, waveTransmissiveFvPatchField< Type >, advectiveFvPatchField< Type >, uniformInletOutletFvPatchField< Type >, inletOutletFvPatchField< Type >, outletInletFvPatchField< Type >, outletInletFvPatchField< Type >, coupledFreestreamFvPatchField< Type >, freestreamFvPatchField< Type >, externalCoupledMixedFvPatchField< Type >, and externalCoupledMixedFvPatchField< scalar >.

Definition at line 181 of file mixedFvPatchField.H.

◆ clone() [2/2]

virtual tmp<fvPatchField<Type> > clone ( const DimensionedField< Type, volMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Public Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

template<class Type> class Foam::mixedFvPatchField< Type >

Constructor & Destructor Documentation

◆ mixedFvPatchField() [1/5]

◆ mixedFvPatchField() [2/5]

◆ mixedFvPatchField() [3/5]

◆ mixedFvPatchField() [4/5]

◆ mixedFvPatchField() [5/5]

Member Function Documentation

◆ TypeName()

◆ clone() [1/2]

◆ clone() [2/2]

◆ fixesValue()

◆ refValue() [1/2]

◆ refValue() [2/2]

◆ refGrad() [1/2]

◆ refGrad() [2/2]

◆ valueFraction() [1/2]

◆ valueFraction() [2/2]

◆ autoMap()

◆ rmap()

◆ snGrad()

◆ evaluate()

◆ valueInternalCoeffs()

◆ valueBoundaryCoeffs()

◆ gradientInternalCoeffs()

◆ gradientBoundaryCoeffs()

◆ write()

◆ operator=() [1/3]

◆ operator=() [2/3]

◆ operator+=() [1/3]

◆ operator-=() [1/3]

◆ operator*=() [1/3]

◆ operator/=() [1/3]

◆ operator+=() [2/3]

◆ operator-=() [2/3]

◆ operator*=() [2/3]

◆ operator/=() [2/3]

◆ operator=() [3/3]

◆ operator+=() [3/3]

◆ operator-=() [3/3]

◆ operator*=() [3/3]

◆ operator/=() [3/3]

Field Documentation

◆ refValue_

◆ refGrad_

◆ valueFraction_

template<class Type>
class Foam::mixedFvPatchField< Type >
