Public Member Functions
	laplaceSmoother (polyMeshGen &, const List< direction > &)
	Construct from mesh and vertex locations. More...

	~laplaceSmoother ()

void	optimizeLaplacian (const label nIterations=1)
	new position is the average of the neighbouring vertices More...

void	optimizeLaplacian (const labelHashSet &badFaces, const label nIterations=1)

void	optimizeSurfaceLaplacian (const labelHashSet &badFaces, const label nIterations=1)

void	optimizeLaplacianPC (const label nIterations=1)

void	optimizeLaplacianPC (const labelHashSet &badFaces, const label nIterations=1)

void	optimizeLaplacianWPC (const label nIterations=1)

void	optimizeLaplacianWPC (const labelHashSet &badFaces, const label nIterations=1)

Private Member Functions
void	laplacian (const labelLongList &, const label)

void	laplacianSurface (const labelLongList &, const label)

void	laplacianParallel (const labelLongList &procPoints, const bool smoothOnlySurfaceNodes=false)

void	laplacianPC (const labelLongList &, const label)

void	laplacianPCParallel (const labelLongList &procPoints)

void	laplacianWPC (const labelLongList &, const label)

void	laplacianWPCParallel (const labelLongList &procPoints)

void	updateMeshGeometry (const labelLongList &smoothPoints)
	update geometry after smoothing More...

	laplaceSmoother (const laplaceSmoother &)
	Disallow default bitwise copy construct. More...

void	operator= (const laplaceSmoother &)
	Disallow default bitwise assignment. More...

Private Attributes
polyMeshGen &	mesh_
	reference to the mesh More...

const List< direction > &	vertexLocation_
	location of vertex (internal, boundary, edge, corner) More...

Detailed Description

Definition at line 95 of file meshOptimizer.H.

Constructor & Destructor Documentation

◆ laplaceSmoother() [1/2]

laplaceSmoother ( const laplaceSmoother & )

private

Disallow default bitwise copy construct.

◆ laplaceSmoother() [2/2]

laplaceSmoother	(	polyMeshGen &	mesh,
		const List< direction > &	vertexLocation
	)

Construct from mesh and vertex locations.

Definition at line 339 of file meshOptimizerOptimizePoint.C.

◆ ~laplaceSmoother()

~laplaceSmoother ( )

Definition at line 350 of file meshOptimizerOptimizePoint.C.

Member Function Documentation

◆ laplacian()

void laplacian	(	const labelLongList &	smoothPoints,
		const label	nIterations
	)

private

smooth the node using the laplacian smoother new position is the average of the neighbouring vertices

Definition at line 47 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, points, VRWGraph::sizeOfRow(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianSurface()

void laplacianSurface	(	const labelLongList &	smoothPoints,
		const label	nIterations
	)

private

Definition at line 94 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, forAllRow, points, and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianParallel()

void laplacianParallel	(	const labelLongList &	procPoints,
		const bool	smoothOnlySurfaceNodes = `false`
	)

private

exchange data between processors

create storage for the data

create data which shall be exchanged with other processors

add data to the list which will be sent to other processor

exchange data with other processors

create new positions of nodes

Definition at line 48 of file meshOptimizerOptimizePointParallel.C.

References LongList< T, Offset >::append(), VRWGraph::contains(), coordinates(), labelledPoint::coordinates(), Foam::endl(), Foam::help::exchangeMap(), forAll, forAllRow, polyMeshGenAddressing::globalPointLabel(), polyMeshGenAddressing::globalToLocalPointAddressing(), refLabelledPoint::lPoint(), Foam::mag(), UPstream::myProcNo(), UPstream::nProcs(), refLabelledPoint::objectLabel(), UPstream::parRun(), pMin(), polyMeshGenAddressing::pointAtProcs(), labelledPoint::pointLabel(), points, Foam::Pout, Foam::returnReduce(), LongList< T, Offset >::size(), VRWGraph::sizeOfRow(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianPC()

void laplacianPC	(	const labelLongList &	smoothPoints,
		const label	nIterations
	)

private

smooth the node using the laplacian smoother new position is the average of the centres of faces attached to the vertex

Definition at line 147 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, forAllRow, points, VRWGraph::sizeOfRow(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianPCParallel()

void laplacianPCParallel ( const labelLongList & procPoints )

private

exchange data between processors

create storage for the data

create data which shall be exchanged with other processors

add data to the list which will be sent to other processor

exchange data with other processors

create new positions of nodes

Definition at line 192 of file meshOptimizerOptimizePointParallel.C.

References LongList< T, Offset >::append(), coordinates(), labelledPoint::coordinates(), Foam::endl(), Foam::help::exchangeMap(), forAll, forAllRow, polyMeshGenAddressing::globalPointLabel(), polyMeshGenAddressing::globalToLocalPointAddressing(), refLabelledPoint::lPoint(), Foam::mag(), UPstream::myProcNo(), refLabelledPoint::objectLabel(), UPstream::parRun(), polyMeshGenAddressing::pointAtProcs(), labelledPoint::pointLabel(), points, Foam::Pout, Foam::returnReduce(), LongList< T, Offset >::size(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianWPC()

void laplacianWPC	(	const labelLongList &	smoothPoints,
		const label	nIterations
	)

private

smooth the node using the laplacian smoother new position is the average of the centres of faces attached to the vertex

Definition at line 199 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, forAllRow, Foam::max(), points, VRWGraph::sizeOfRow(), w(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ laplacianWPCParallel()

void laplacianWPCParallel ( const labelLongList & procPoints )

private

exchange data between processors

create storage for the data

create data which shall be exchanged with other processors

add data to the list which will be sent to other processor

exchange data with other processors

create new positions of nodes

Definition at line 322 of file meshOptimizerOptimizePointParallel.C.

References LongList< T, Offset >::append(), coordinates(), labelledPointScalar::coordinates(), Foam::endl(), Foam::help::exchangeMap(), forAll, forAllRow, polyMeshGenAddressing::globalPointLabel(), polyMeshGenAddressing::globalToLocalPointAddressing(), Foam::mag(), Foam::max(), UPstream::myProcNo(), UPstream::parRun(), polyMeshGenAddressing::pointAtProcs(), labelledPointScalar::pointLabel(), points, Foam::Pout, Foam::returnReduce(), labelledPointScalar::scalarValue(), LongList< T, Offset >::size(), w(), and Vector< scalar >::zero.

Here is the call graph for this function:

◆ updateMeshGeometry()

void updateMeshGeometry ( const labelLongList & smoothPoints )

private

update geometry after smoothing

make sure that neighbouring processors get the same information

update geometry information

Definition at line 258 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), UPstream::blocking, LongList< T, Offset >::byteSize(), Foam::constant::universal::c, cells, forAll, and forAllRow.

Here is the call graph for this function:

◆ operator=()

void operator= ( const laplaceSmoother & )

private

Disallow default bitwise assignment.

◆ optimizeLaplacian() [1/2]

void optimizeLaplacian ( const label nIterations = 1 )

new position is the average of the neighbouring vertices

Definition at line 356 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, meshOptimizer::INSIDE, Foam::fvc::laplacian(), and meshOptimizer::vertexLocation_.

Here is the call graph for this function:

◆ optimizeLaplacian() [2/2]

void optimizeLaplacian	(	const labelHashSet &	badFaces,
		const label	nIterations = `1`
	)

Definition at line 370 of file meshOptimizerOptimizePoint.C.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

◆ optimizeSurfaceLaplacian()

void optimizeSurfaceLaplacian	(	const labelHashSet &	badFaces,
		const label	nIterations = `1`
	)

new position of surface point is the average of the neighbouring surface vertices

Definition at line 379 of file meshOptimizerOptimizePoint.C.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

◆ optimizeLaplacianPC() [1/2]

void optimizeLaplacianPC ( const label nIterations = 1 )

new positions are the average of the centres of the cells adjacent to the vertex

Definition at line 388 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, meshOptimizer::INSIDE, and meshOptimizer::vertexLocation_.

Referenced by meshOptimizer::optimizeMeshFV().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ optimizeLaplacianPC() [2/2]

void optimizeLaplacianPC	(	const labelHashSet &	badFaces,
		const label	nIterations = `1`
	)

Definition at line 404 of file meshOptimizerOptimizePoint.C.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

◆ optimizeLaplacianWPC() [1/2]

void optimizeLaplacianWPC ( const label nIterations = 1 )

new positions are the average of the centres of the cells adjacent to the vertex weighted by cell volumes

Definition at line 413 of file meshOptimizerOptimizePoint.C.

References LongList< T, Offset >::append(), forAll, meshOptimizer::INSIDE, and meshOptimizer::vertexLocation_.

Here is the call graph for this function:

◆ optimizeLaplacianWPC() [2/2]

void optimizeLaplacianWPC	(	const labelHashSet &	badFaces,
		const label	nIterations = `1`
	)

Definition at line 429 of file meshOptimizerOptimizePoint.C.

References Foam::exit(), and Foam::FatalError.

Here is the call graph for this function:

Field Documentation

◆ mesh_

polyMeshGen& mesh_

private

reference to the mesh

Definition at line 99 of file meshOptimizer.H.

◆ vertexLocation_

const List<direction>& vertexLocation_

private

location of vertex (internal, boundary, edge, corner)

Definition at line 102 of file meshOptimizer.H.
