maxwellSlipUFvPatchVectorField Class Reference

Maxwell slip boundary condition including thermal creep and surface curvature terms that can be optionally switched off. More...

Inheritance diagram for maxwellSlipUFvPatchVectorField:

Collaboration diagram for maxwellSlipUFvPatchVectorField:

Public Member Functions
	TypeName ("maxwellSlipU")
	Runtime type information. More...
	maxwellSlipUFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &)
	Construct from patch and internal field. More...
	maxwellSlipUFvPatchVectorField (const fvPatch &, const DimensionedField< vector, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...
	maxwellSlipUFvPatchVectorField (const maxwellSlipUFvPatchVectorField &, const fvPatch &, const DimensionedField< vector, volMesh > &, const fvPatchFieldMapper &)
	Construct by mapping given. More...
virtual tmp< fvPatchVectorField >	clone () const
	Construct and return a clone. More...
	maxwellSlipUFvPatchVectorField (const maxwellSlipUFvPatchVectorField &, const DimensionedField< vector, volMesh > &)
	Construct as copy setting internal field reference. More...
virtual tmp< fvPatchVectorField >	clone (const DimensionedField< vector, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...
virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...
virtual void	write (Ostream &) const
	Write. More...

Private Attributes
word	TName_
	Temperature field name, default = "T". More...
word	rhoName_
	Density field name, default = "rho". More...
word	psiName_
	Compressibility field name, default = "thermo:psi". More...
word	muName_
	Dynamic viscosity field name, default = "thermo:mu". More...
word	tauMCName_
	tauMC field name, default = "tauMC" More...
scalar	accommodationCoeff_
vectorField	Uwall_
Switch	thermalCreep_
Switch	curvature_

Detailed Description

Maxwell slip boundary condition including thermal creep and surface curvature terms that can be optionally switched off.

Source files

• maxwellSlipUFvPatchVectorField.H
• fixedRhoFvPatchScalarField.C

Definition at line 50 of file maxwellSlipUFvPatchVectorField.H.

Constructor & Destructor Documentation

maxwellSlipUFvPatchVectorField() [1/4]

maxwellSlipUFvPatchVectorField	(	const fvPatch &	,
		const DimensionedField< vector, volMesh > &
	)

Construct from patch and internal field.

Referenced by maxwellSlipUFvPatchVectorField::clone().

Here is the caller graph for this function:

maxwellSlipUFvPatchVectorField() [2/4]

maxwellSlipUFvPatchVectorField	(	const fvPatch &	,
		const DimensionedField< vector, volMesh > &	,
		const dictionary &
	)

Construct from patch, internal field and dictionary.

maxwellSlipUFvPatchVectorField() [3/4]

maxwellSlipUFvPatchVectorField	(	const maxwellSlipUFvPatchVectorField &	,
		const fvPatch &	,
		const DimensionedField< vector, volMesh > &	,
		const fvPatchFieldMapper &
	)

Construct by mapping given.

maxwellSlipUFvPatchVectorField onto a new patch

maxwellSlipUFvPatchVectorField() [4/4]

maxwellSlipUFvPatchVectorField	(	const maxwellSlipUFvPatchVectorField &	,
		const DimensionedField< vector, volMesh > &
	)

Construct as copy setting internal field reference.

Member Function Documentation

TypeName()

TypeName

(

"maxwellSlipU"

)

Runtime type information.

clone() [1/2]

virtual tmp<fvPatchVectorField> clone ( ) const

inlinevirtual

Construct and return a clone.

Definition at line 118 of file maxwellSlipUFvPatchVectorField.H.

References maxwellSlipUFvPatchVectorField::maxwellSlipUFvPatchVectorField().

Here is the call graph for this function:

clone() [2/2]

virtual tmp<fvPatchVectorField> clone ( const DimensionedField< vector, volMesh > &  iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 135 of file maxwellSlipUFvPatchVectorField.H.

References maxwellSlipUFvPatchVectorField::maxwellSlipUFvPatchVectorField().

Here is the call graph for this function:

updateCoeffs()

virtual void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

write()

virtual void write ( Ostream &  ) const

virtual

Write.

Field Documentation

TName_

word TName_

private

Temperature field name, default = "T".

Definition at line 57 of file maxwellSlipUFvPatchVectorField.H.

rhoName_

word rhoName_

private

Density field name, default = "rho".

Definition at line 60 of file maxwellSlipUFvPatchVectorField.H.

psiName_

word psiName_

private

Compressibility field name, default = "thermo:psi".

Definition at line 63 of file maxwellSlipUFvPatchVectorField.H.

muName_

word muName_

private

Dynamic viscosity field name, default = "thermo:mu".

Definition at line 66 of file maxwellSlipUFvPatchVectorField.H.

tauMCName_

word tauMCName_

private

tauMC field name, default = "tauMC"

Definition at line 69 of file maxwellSlipUFvPatchVectorField.H.

accommodationCoeff_

scalar accommodationCoeff_

private

Definition at line 72 of file maxwellSlipUFvPatchVectorField.H.

Uwall_

vectorField Uwall_

private

Definition at line 75 of file maxwellSlipUFvPatchVectorField.H.

thermalCreep_

Switch thermalCreep_

private

Definition at line 78 of file maxwellSlipUFvPatchVectorField.H.

curvature_

Switch curvature_

private

Definition at line 81 of file maxwellSlipUFvPatchVectorField.H.

---

The documentation for this class was generated from the following file:

• applications/solvers/compressible/rhoCentralFoam/BCs/U/maxwellSlipUFvPatchVectorField.H
