Class containing mesh-to-mesh mapping information after a subset operation. More...

Inheritance diagram for mapSubsetMesh:

Collaboration diagram for mapSubsetMesh:

[legend]

Public Member Functions
	mapSubsetMesh (const label nOldPoints, const label nOldFaces, const label nOldCells, const labelList &pointMap, const labelList &faceMap, const labelList &cellMap, const label exposedPatchID, const labelList &oldPatchStarts, const labelList &oldPatchNMeshPoints)
	Construct from components. More...

	mapSubsetMesh (const label nOldPoints, const label nOldFaces, const label nOldCells, labelList &pointMap, labelList &faceMap, labelList &cellMap, const label exposedPatchID, labelList &oldPatchStarts, labelList &oldPatchNMeshPoints, const bool reUse)
	Construct from components and optionally reuse storage. More...

label	nOldPoints () const
	Number of old points. More...

label	nOldInternalFaces () const
	Number of old internal faces. More...

label	nOldFaces () const
	Number of old faces. More...

label	nOldCells () const
	Number of old cells. More...

label	exposedPatchID () const
	Patch that exposed faces were put into. More...

const labelList &	pointMap () const
	Old point map. More...

const labelList &	faceMap () const
	Old face map. More...

const labelList &	cellMap () const
	Old cell map. More...

const labelList &	oldPatchSizes () const
	Return list of the old patch sizes. More...

const labelList &	oldPatchStarts () const
	Return list of the old patch start labels. More...

const labelList &	oldPatchNMeshPoints () const
	Return numbers of mesh points per old patch. More...

Public Member Functions inherited from refCount
	refCount ()
	Construct null with zero count. More...

int	count () const
	Return the reference count. More...

bool	okToDelete () const
	Return true if the reference count is zero. More...

void	resetRefCount ()
	Reset the reference count to zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

Private Attributes
label	nOldPoints_
	Number of old live points. More...

label	nOldFaces_
	Number of old live faces. More...

label	nOldCells_
	Number of old live cells. More...

const labelList	pointMap_
	Point mapping array. More...

const labelList	faceMap_
	Face mapping array. More...

const labelList	cellMap_
	Cell mapping array. More...

const label	exposedPatchID_
	Patch for exposed faces. More...

labelList	oldPatchSizes_
	List of the old patch sizes. More...

const labelList	oldPatchStarts_
	List of the old patch start labels. More...

const labelList	oldPatchNMeshPoints_
	List of numbers of mesh points per old patch. More...

Detailed Description

Class containing mesh-to-mesh mapping information after a subset operation.

Source files

mapSubsetMesh.H

Definition at line 48 of file mapSubsetMesh.H.

Constructor & Destructor Documentation

◆ mapSubsetMesh() [1/2]

mapSubsetMesh	(	const label	nOldPoints,
		const label	nOldFaces,
		const label	nOldCells,
		const labelList &	pointMap,
		const labelList &	faceMap,
		const labelList &	cellMap,
		const label	exposedPatchID,
		const labelList &	oldPatchStarts,
		const labelList &	oldPatchNMeshPoints
	)

Construct from components.

◆ mapSubsetMesh() [2/2]

mapSubsetMesh	(	const label	nOldPoints,
		const label	nOldFaces,
		const label	nOldCells,
		labelList &	pointMap,
		labelList &	faceMap,
		labelList &	cellMap,
		const label	exposedPatchID,
		labelList &	oldPatchStarts,
		labelList &	oldPatchNMeshPoints,
		const bool	reUse
	)

Construct from components and optionally reuse storage.

Member Function Documentation

◆ nOldPoints()

label nOldPoints ( ) const

inline

Number of old points.

Definition at line 123 of file mapSubsetMesh.H.

References mapSubsetMesh::nOldPoints_.

◆ nOldInternalFaces()

label nOldInternalFaces ( ) const

inline

Number of old internal faces.

Definition at line 129 of file mapSubsetMesh.H.

References mapSubsetMesh::oldPatchStarts_.

◆ nOldFaces()

label nOldFaces ( ) const

inline

Number of old faces.

Definition at line 135 of file mapSubsetMesh.H.

References mapSubsetMesh::nOldFaces_.

◆ nOldCells()

label nOldCells ( ) const

inline

Number of old cells.

Definition at line 141 of file mapSubsetMesh.H.

References mapSubsetMesh::nOldCells_.

◆ exposedPatchID()

label exposedPatchID ( ) const

inline

Patch that exposed faces were put into.

Definition at line 147 of file mapSubsetMesh.H.

References mapSubsetMesh::exposedPatchID_.

◆ pointMap()

const labelList& pointMap ( ) const

inline

Old point map.

Contains the old point label for all points of the subsetted mesh

Definition at line 155 of file mapSubsetMesh.H.

◆ faceMap()

const labelList& faceMap ( ) const

inline

Old face map.

Contains the old point label for all faces of the subsetted mesh

Definition at line 163 of file mapSubsetMesh.H.

◆ cellMap()

const labelList& cellMap ( ) const

inline

Old cell map.

Contains the old point label for all cells of the subsetted mesh

Definition at line 171 of file mapSubsetMesh.H.

◆ oldPatchSizes()

const labelList& oldPatchSizes ( ) const

inline

Return list of the old patch sizes.

Definition at line 177 of file mapSubsetMesh.H.

References mapSubsetMesh::oldPatchSizes_.

◆ oldPatchStarts()

const labelList& oldPatchStarts ( ) const

inline

Return list of the old patch start labels.

Definition at line 183 of file mapSubsetMesh.H.

References mapSubsetMesh::oldPatchStarts_.

◆ oldPatchNMeshPoints()

const labelList& oldPatchNMeshPoints ( ) const

inline

Return numbers of mesh points per old patch.

Definition at line 189 of file mapSubsetMesh.H.

References mapSubsetMesh::oldPatchNMeshPoints_.

Field Documentation

◆ nOldPoints_

label nOldPoints_

private

Number of old live points.

Definition at line 55 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::nOldPoints().

◆ nOldFaces_

label nOldFaces_

private

Number of old live faces.

Definition at line 58 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::nOldFaces().

◆ nOldCells_

label nOldCells_

private

Number of old live cells.

Definition at line 61 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::nOldCells().

◆ pointMap_

const labelList pointMap_

private

Point mapping array.

Definition at line 64 of file mapSubsetMesh.H.

◆ faceMap_

const labelList faceMap_

private

Face mapping array.

Definition at line 67 of file mapSubsetMesh.H.

◆ cellMap_

const labelList cellMap_

private

Cell mapping array.

Definition at line 70 of file mapSubsetMesh.H.

◆ exposedPatchID_

const label exposedPatchID_

private

Patch for exposed faces.

Definition at line 73 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::exposedPatchID().

◆ oldPatchSizes_

labelList oldPatchSizes_

private

List of the old patch sizes.

Definition at line 76 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::oldPatchSizes().

◆ oldPatchStarts_

const labelList oldPatchStarts_

private

List of the old patch start labels.

Definition at line 79 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::nOldInternalFaces(), and mapSubsetMesh::oldPatchStarts().

◆ oldPatchNMeshPoints_

const labelList oldPatchNMeshPoints_

private

List of numbers of mesh points per old patch.

Definition at line 82 of file mapSubsetMesh.H.

Referenced by mapSubsetMesh::oldPatchNMeshPoints().

The documentation for this class was generated from the following file:

src/OpenFOAM/meshes/polyMesh/mapPolyMesh/mapSubsetMesh/mapSubsetMesh.H
