Incompressible, polynomial form of equation of state, using a polynomial function for density. More...

Collaboration diagram for icoPolynomial:

Public Member Functions
	icoPolynomial (const Specie &sp, const Polynomial< PolySize > &rhoPoly)
	Construct from components. More...

	icoPolynomial (Istream &)
	Construct from Istream. More...

	icoPolynomial (const dictionary &dict)
	Construct from dictionary. More...

	icoPolynomial (const icoPolynomial &)
	Construct as copy. More...

	icoPolynomial (const word &name, const icoPolynomial &)
	Construct as named copy. More...

autoPtr< icoPolynomial >	clone () const
	Construct and return a clone. More...

scalar	rho (scalar p, scalar T) const
	Return density [kg/m^3]. More...

scalar	s (const scalar p, const scalar T) const
	Return entropy [J/(kmol K)]. More...

scalar	psi (scalar p, scalar T) const
	Return compressibility rho/p [s^2/m^2]. More...

scalar	Z (scalar p, scalar T) const
	Return compression factor []. More...

scalar	cpMcv (scalar p, scalar T) const
	Return (cp - cv) [J/(kmol K]. More...

void	write (Ostream &os) const
	Write to Ostream. More...

icoPolynomial &	operator= (const icoPolynomial &)

void	operator+= (const icoPolynomial &)

void	operator-= (const icoPolynomial &)

void	operator*= (const scalar)

Static Public Member Functions
static autoPtr< icoPolynomial >	New (Istream &is)

static autoPtr< icoPolynomial >	New (const dictionary &dict)

static word	typeName ()
	Return the instantiated type name. More...

Static Public Attributes
static const bool	incompressible = true
	Is the equation of state is incompressible i.e. rho != f(p) More...

static const bool	isochoric = false
	Is the equation of state is isochoric i.e. rho = const. More...

Private Attributes
Polynomial< PolySize >	rhoCoeffs_
	Density polynomial coefficients. More...

Friends
icoPolynomial	operator+ (const icoPolynomial &, const icoPolynomial &)

icoPolynomial	operator- (const icoPolynomial &, const icoPolynomial &)

icoPolynomial	operator* (const scalar s, const icoPolynomial &)

icoPolynomial	operator== (const icoPolynomial &, const icoPolynomial &)

Ostream &	operator (Ostream &, const icoPolynomial &)

Detailed Description

Incompressible, polynomial form of equation of state, using a polynomial function for density.

Source files

Definition at line 50 of file icoPolynomial.H.

Constructor & Destructor Documentation

◆ icoPolynomial() [1/5]

icoPolynomial	(	const Specie &	sp,
		const Polynomial< PolySize > &	rhoPoly
	)

inline

Construct from components.

◆ icoPolynomial() [2/5]

icoPolynomial ( Istream & )

Construct from Istream.

◆ icoPolynomial() [3/5]

icoPolynomial ( const dictionary & dict )

Construct from dictionary.

Definition at line 47 of file icoPolynomial.C.

References icoPolynomial::rhoCoeffs_.

◆ icoPolynomial() [4/5]

icoPolynomial ( const icoPolynomial & )

inline

Construct as copy.

◆ icoPolynomial() [5/5]

icoPolynomial	(	const word &	name,
		const icoPolynomial &
	)

inline

Construct as named copy.

Member Function Documentation

◆ clone()

Foam::autoPtr< Foam::icoPolynomial< Specie, PolySize > > clone ( ) const

inline

Construct and return a clone.

Definition at line 69 of file icoPolynomialI.H.

◆ New() [1/2]

Foam::autoPtr< Foam::icoPolynomial< Specie, PolySize > > New ( Istream & is )

inlinestatic

Definition at line 80 of file icoPolynomialI.H.

◆ New() [2/2]

Foam::autoPtr< Foam::icoPolynomial< Specie, PolySize > > New ( const dictionary & dict )

inlinestatic

Definition at line 91 of file icoPolynomialI.H.

References dict.

◆ typeName()

static word typeName ( )

inlinestatic

Return the instantiated type name.

Definition at line 140 of file icoPolynomial.H.

◆ rho()

Foam::scalar rho	(	scalar	p,
		scalar	T
	)		const

inline

Return density [kg/m^3].

Definition at line 104 of file icoPolynomialI.H.

References T.

◆ s()

Foam::scalar s	(	const scalar	p,
		const scalar	T
	)		const

inline

Return entropy [J/(kmol K)].

Definition at line 115 of file icoPolynomialI.H.

◆ psi()

Foam::scalar psi	(	scalar	p,
		scalar	T
	)		const

inline

Return compressibility rho/p [s^2/m^2].

Definition at line 126 of file icoPolynomialI.H.

◆ Z()

Foam::scalar Z	(	scalar	p,
		scalar	T
	)		const

inline

Return compression factor [].

Definition at line 137 of file icoPolynomialI.H.

◆ cpMcv()

Foam::scalar cpMcv	(	scalar	p,
		scalar	T
	)		const

inline

Return (cp - cv) [J/(kmol K].

Definition at line 148 of file icoPolynomialI.H.

References p, Foam::sqr(), and T.

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

Write to Ostream.

Definition at line 65 of file icoPolynomial.C.

References dictionary::add(), dict, dictionaryName::dictName(), Foam::indent(), Foam::name(), PolySize, and write().

Here is the call graph for this function:

◆ operator=()

Foam::icoPolynomial< Specie, PolySize > & operator= ( const icoPolynomial & )

inline

Definition at line 162 of file icoPolynomialI.H.

◆ operator+=()

void operator+= ( const icoPolynomial & )

inline

Definition at line 176 of file icoPolynomialI.H.

◆ operator-=()

void operator-= ( const icoPolynomial & )

inline

Definition at line 193 of file icoPolynomialI.H.

◆ operator*=()

void operator*= ( const scalar s )

inline

Definition at line 209 of file icoPolynomialI.H.

References s().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator+

icoPolynomial operator+	(	const icoPolynomial &	,
		const icoPolynomial &
	)

friend

◆ operator-

icoPolynomial operator-	(	const icoPolynomial &	,
		const icoPolynomial &
	)

friend

◆ operator*

icoPolynomial operator*	(	const scalar	s,
		const icoPolynomial &
	)

friend

◆ operator==

icoPolynomial operator==	(	const icoPolynomial &	,
		const icoPolynomial &
	)

friend

◆ operator

Ostream& operator	(	Ostream &	,
		const icoPolynomial &
	)

friend

Field Documentation

◆ rhoCoeffs_

Polynomial<PolySize> rhoCoeffs_

private

Density polynomial coefficients.

Note: input in [kg/m3], but internally uses [kg/m3/kmol]

Definition at line 101 of file icoPolynomial.H.

Referenced by icoPolynomial::icoPolynomial(), and Foam::operator<<().

◆ incompressible

const bool incompressible = true

static

Is the equation of state is incompressible i.e. rho != f(p)

Definition at line 149 of file icoPolynomial.H.

◆ isochoric

const bool isochoric = false

static

Is the equation of state is isochoric i.e. rho = const.

Definition at line 152 of file icoPolynomial.H.

The documentation for this class was generated from the following files:

src/thermophysicalModels/specie/equationOfState/icoPolynomial/icoPolynomial.H
src/thermophysicalModels/specie/equationOfState/icoPolynomial/icoPolynomial.C
src/thermophysicalModels/specie/equationOfState/icoPolynomial/icoPolynomialI.H
