An STL-conforming hash table. More...

Collaboration diagram for HashTable:

Data Structures
class	const_iterator
	An STL-conforming const_iterator. More...

struct	hashedEntry
	Structure to hold a hashed entry with SLList for collisions. More...

class	iterator
	An STL-conforming iterator. More...

class	iteratorBase
	The iterator base for HashTable. More...

Public Types
typedef T	value_type
	Type of values the HashTable contains. More...

typedef T &	reference
	Type that can be used for storing into HashTable::value_type. More...

typedef label	size_type
	The type that can represent the size of a HashTable. More...

Public Member Functions
	HashTable (const label size=128)
	Construct given initial table size. More...

	HashTable (Istream &, const label size=128)
	Construct from Istream. More...

	HashTable (const HashTable< T, Key, Hash > &)
	Construct as copy. More...

	HashTable (const Xfer< HashTable< T, Key, Hash > > &)
	Construct by transferring the parameter contents. More...

	~HashTable ()
	Destructor. More...

label	capacity () const
	The size of the underlying table. More...

label	size () const
	Return number of elements in table. More...

bool	empty () const
	Return true if the hash table is empty. More...

bool	found (const Key &) const
	Return true if hashedEntry is found in table. More...

iterator	find (const Key &)
	Find and return an iterator set at the hashedEntry. More...

const_iterator	find (const Key &) const
	Find and return an const_iterator set at the hashedEntry. More...

List< Key >	toc () const
	Return the table of contents. More...

List< Key >	sortedToc () const
	Return the table of contents as a sorted list. More...

Ostream &	printInfo (Ostream &) const
	Print information. More...

bool	insert (const Key &, const T &newElmt)
	Insert a new hashedEntry. More...

bool	set (const Key &, const T &newElmt)
	Assign a new hashedEntry, overwriting existing entries. More...

bool	erase (const iterator &)
	Erase a hashedEntry specified by given iterator. More...

bool	erase (const Key &)
	Erase a hashedEntry specified by the given key. More...

label	erase (const UList< Key > &)
	Remove entries given by the listed keys from this HashTable. More...

template<class AnyType , class AnyHash >
label	erase (const HashTable< AnyType, Key, AnyHash > &)
	Remove entries given by the given keys from this HashTable. More...

void	resize (const label newSize)
	Resize the hash table for efficiency. More...

void	clear ()
	Clear all entries from table. More...

void	clearStorage ()
	Clear the table entries and the table itself. More...

void	shrink ()
	Shrink the allocated table to approx. twice number of elements. More...

void	transfer (HashTable< T, Key, Hash > &)
	Transfer the contents of the argument table into this table. More...

Xfer< HashTable< T, Key, Hash > >	xfer ()
	Transfer contents to the Xfer container. More...

T &	operator[] (const Key &)
	Find and return a hashedEntry. More...

const T &	operator[] (const Key &) const
	Find and return a hashedEntry. More...

T &	operator() (const Key &)
	Find and return a hashedEntry, create it null if not present. More...

void	operator= (const HashTable< T, Key, Hash > &)
	Assignment. More...

bool	operator== (const HashTable< T, Key, Hash > &) const
	Equality. Hash tables are equal if the keys and values are equal. More...

bool	operator!= (const HashTable< T, Key, Hash > &) const
	The opposite of the equality operation. Takes linear time. More...

iterator	begin ()
	Iterator set to the beginning of the HashTable. More...

const_iterator	cbegin () const
	const_iterator set to the beginning of the HashTable More...

const_iterator	begin () const
	const_iterator set to the beginning of the HashTable More...

template<class AnyType , class AnyHash >
Foam::label	erase (const HashTable< AnyType, Key, AnyHash > &rhs)

Data Fields
const typedef T &	const_reference
	Type that can be used for storing into constant. More...

Private Member Functions
label	hashKeyIndex (const Key &) const
	Return the hash index of the Key within the current table size. More...

bool	set (const Key &, const T &newElmt, bool protect)
	Assign a new hashedEntry to a possibly already existing key. More...

Static Private Member Functions
static label	canonicalSize (const label)
	Return a canonical (power-of-two) size. More...

Private Attributes
label	nElmts_
	The current number of elements in table. More...

label	tableSize_
	Number of primary entries allocated in table. More...

hashedEntry **	table_
	The table of primary entries. More...

Friends
template<class T2 , class Key2 , class Hash2 >
class	HashPtrTable
	Declare friendship with the HashPtrTable class. More...

class	iteratorBase
	Declare friendship with the iteratorBase. More...

class	iterator
	Declare friendship with the iterator. More...

class	const_iterator
	Declare friendship with the const_iterator. More...

Istream &	operator>> (Istream &, HashTable< T, Key, Hash > &)

Ostream &	operator (Ostream &, const HashTable< T, Key, Hash > &)

Detailed Description

An STL-conforming hash table.

Note: Hashing index collisions are handled via chaining using a singly-linked list with the colliding entry being added to the head of the linked list. Thus copying the hash table (or indeed even resizing it) will often result in a different hash order. Use a sorted table-of-contents when the hash order is important.

Source files

Definition at line 61 of file HashTable.H.

Member Typedef Documentation

◆ value_type

typedef T value_type

Type of values the HashTable contains.

Definition at line 321 of file HashTable.H.

◆ reference

typedef T& reference

Type that can be used for storing into HashTable::value_type.

objects. This type is usually List::value_type&.

Definition at line 325 of file HashTable.H.

◆ size_type

typedef label size_type

The type that can represent the size of a HashTable.

Definition at line 333 of file HashTable.H.

Constructor & Destructor Documentation

◆ HashTable() [1/4]

HashTable ( const label size = 128 )

Construct given initial table size.

◆ HashTable() [2/4]

HashTable	(	Istream &	,
		const label	size = `128`
	)

Construct from Istream.

◆ HashTable() [3/4]

HashTable ( const HashTable< T, Key, Hash > & )

Construct as copy.

◆ HashTable() [4/4]

HashTable ( const Xfer< HashTable< T, Key, Hash > > & )

Construct by transferring the parameter contents.

◆ ~HashTable()

~HashTable ( )

Destructor.

Definition at line 96 of file HashTable.C.

Member Function Documentation

◆ canonicalSize()

static label canonicalSize ( const label )

staticprivate

Return a canonical (power-of-two) size.

◆ hashKeyIndex()

Foam::label hashKeyIndex ( const Key & key ) const

inlineprivate

Return the hash index of the Key within the current table size.

No checks for zero-sized tables.

Definition at line 48 of file HashTableI.H.

◆ set() [1/2]

bool set	(	const Key &	,
		const T &	newElmt,
		bool	protect
	)

private

Assign a new hashedEntry to a possibly already existing key.

Referenced by main().

Here is the caller graph for this function:

◆ capacity()

Foam::label capacity ( ) const

inline

The size of the underlying table.

Definition at line 58 of file HashTableI.H.

Referenced by main().

Here is the caller graph for this function:

◆ size()

Foam::label size ( ) const

inline

Return number of elements in table.

Definition at line 65 of file HashTableI.H.

Referenced by singleProcessorFaceSetsConstraint::add(), polyMeshGenModifier::addBufferCells(), normalToFace::applyToSet(), cellCuts::calcAnchors(), polyDualMesh::calcDual(), FECCellToFaceStencil::calcFaceStencil(), cellToFaceStencil::calcFaceStencil(), globalMeshData::calcSharedEdges(), meshSurfacePartitioner::calculateCornersEdgesAndAddressing(), triSurfAddressing::calculateFacetFacetsEdges(), globalPoints::calculateSharedPoints(), boundaryMesh::changeFaces(), checkIrregularSurfaceConnections::checkAndFixIrregularConnections(), meshOctreeAddressing::checkAndFixIrregularConnections(), autoLayerDriver::checkAndUnmark(), polyMesh::checkEdgeAlignment(), primitiveMesh::checkEdgeAlignment(), checkIrregularSurfaceConnections::checkEdgeFaceConnections(), primitiveMesh::checkEdgeLength(), checkIrregularSurfaceConnections::checkFaceGroupsAtBndVertices(), edgeExtractor::checkFacePatchesGeometry(), Foam::checkGeometry(), meshOctreeAddressing::checkGluedRegions(), motionSmootherAlgo::checkMesh(), autoLayerDriver::checkMeshManifold(), Foam::checkMeshQuality(), edgeCollapser::checkMeshQuality(), Foam::checkTopology(), coalCloudList::coalCloudList(), faceToCell::combine(), pointToFace::combine(), hexRef8::consistentSlowRefinement2(), meshToMesh::constructFromCuttingPatches(), inversePointDistanceDiffusivity::correct(), cyclicPolyPatch::coupledEdges(), autoRefineDriver::danglingCellRefine(), doCommand(), autoLayerDriver::doLayers(), autoRefineDriver::doRefine(), autoSnapDriver::doSnap(), extractSurface(), combineFaces::faceNeighboursValid(), meshOptimizer::findBadFaces(), Foam::polyMeshGenChecks::findBadFaces(), Foam::polyMeshGenChecks::findBadFacesRelaxed(), findBaffles(), meshRefinement::findEdgeConnectedProblemCells(), meshOptimizer::findLowQualityFaces(), Foam::polyMeshGenChecks::findLowQualityFaces(), findMatches(), faceCoupleInfo::findSlavesCoveringMaster(), Foam::polyMeshGenChecks::findWorstQualityFaces(), surfaceSets::getHangingCells(), combineFaces::getMergeSets(), cellDistFuncs::getPointNeighbours(), removePoints::getUnrefimentSet(), autoLayerDriver::handleNonManifolds(), meshRefinement::handleSnapProblems(), injectionModelList::injectionModelList(), Foam::interpolatePointToCell(), topoSet::invert(), layerParameters::layerParameters(), main(), immersedBoundaryFvPatch::makeTriAddressing(), fvMeshDistribute::mapBoundaryFields(), fvMeshDistribute::mapExposedFaces(), meshRefinement::markFacesOnProblemCells(), meshRefinement::markFacesOnProblemCellsGeometric(), meshRefinement::markFeatureCellLevel(), meshToMesh::maskCells(), polyBoundaryMesh::matchGroups(), cellToCellStencil::merge(), cellToFaceStencil::merge(), Foam::mergeAndWrite(), edgeMesh::mergeEdges(), meshRefinement::mergeEdgesUndo(), meshRefinement::mergePatchFacesUndo(), surfaceMorpherCells::morphBoundaryFaces(), surfaceMorpherCells::morphInternalFaces(), MRFZone::MRFZone(), polyBoundaryMesh::neighbourEdges(), Foam::help::numberOfEdgeGroups(), Foam::help::numberOfFaceGroups(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator==(), symmetryPlaneOptimisation::optimizeSymmetryPlanes(), Foam::polyMeshZipUpCells(), printAllSets(), wallBoundedStreamLine::read(), dynamicRefineFvMesh::refine(), autoRefineDriver::refinementInterfaceRefine(), checkNonMappableCellConnections::removeCells(), structuredRenumber::renumber(), polyTopoChange::renumber(), faceAreaWeightAMI< SourcePatch, TargetPatch >::restartUncoveredSourceFace(), fvMeshDistribute::saveBoundaryFields(), fvMeshDistribute::saveInternalFields(), motionSmootherAlgo::scaleMesh(), MRFZone::setMRFFaces(), removePoints::setRefinement(), hexRef8::setRefinement(), hexRef8::setUnrefinement(), meshRefinement::splitFacesUndo(), topoSet::subset(), surfaceFeatures::surfaceFeatures(), extendedUpwindCellToFaceStencil::transportStencil(), meshOptimizer::untangleBoundaryLayer(), updateCellSet(), domainDecomposition::writeDecomposition(), autoLayerDriver::writeLayerSets(), writeVTK(), inverseDistanceDiffusivity::y(), polyMeshGenModifier::zipUpCells(), and meshRefinement::zonify().

◆ empty()

bool empty ( ) const

inline

Return true if the hash table is empty.

Definition at line 72 of file HashTableI.H.

Referenced by forces::calcForcesMoment(), patchToFace::combine(), and globalIndexAndTransform::transformIndicesForPatches().

Here is the caller graph for this function:

◆ found()

bool found ( const Key & key ) const

Return true if hashedEntry is found in table.

Definition at line 109 of file HashTable.C.

Referenced by refineImmersedBoundaryMesh::addIbCellCellFaces(), refineImmersedBoundaryMesh::addIbCellCells(), refineImmersedBoundaryMesh::addIbCells(), immersedBoundaryFvPatch::addIbCornerCells(), autoLayerDriver::addLayers(), fieldAverage::addMeanFieldType(), searchableSurfaceToFaceZone::applyToSet(), setToCellZone::applyToSet(), faceZoneToFaceZone::applyToSet(), setToPointZone::applyToSet(), setToFaceZone::applyToSet(), setAndNormalToFaceZone::applyToSet(), setsToFaceZone::applyToSet(), meshToMesh0::calcAddressing(), meshSurfaceEngine::calcGlobalBoundaryPointLabels(), meshRefinement::calcNeighbourData(), meshSurfaceEngine::calculateBoundaryNodes(), boundaryLayerOptimisation::calculateHairEdges(), autoLayerDriver::cellsUseFace(), meshOctreeAddressing::checkAndFixIrregularConnections(), Foam::polyMeshGenChecks::checkCellPartTetrahedra(), edgeExtractor::checkCorners(), checkIrregularSurfaceConnections::checkEdgeFaceConnections(), decomposeCells::checkFaceConnections(), Foam::polyMeshGenChecks::checkFaceFlatness(), edgeExtractor::checkFacePatchesGeometry(), Foam::polyMeshGenChecks::checkFacePyramids(), meshOctreeAddressing::checkGluedRegions(), edgeMeshFormatsCore::checkSupport(), surfaceFormatsCore::checkSupport(), boundaryLayers::checkTopologyOfBoundaryFaces(), meshSurfaceCheckInvertedVertices::checkVertices(), triSurfaceTools::collapseCreatesFold(), triSurfaceTools::collapseMinCosAngle(), meshRefinement::collectFaces(), pointToCell::combine(), pointToFace::combine(), cellToFace::combine(), inverseFaceDistanceDiffusivity::correct(), inversePointDistanceDiffusivity::correct(), motionSmootherAlgo::correctBoundaryConditions(), cellDistFuncs::correctBoundaryFaceCells(), cellDistFuncs::correctBoundaryPointCells(), slidingInterface::coupleInterface(), boundaryLayers::createLayerCells(), edgeExtractor::cornerEvaluator::createParallelAddressing(), curvatureSeparation::curvatureSeparation(), hexCellLooper::cut(), geomCellLooper::cut(), Foam::meshTools::cutDirToEdge(), cellZoneSet::deleteSet(), pointZoneSet::deleteSet(), attachDetach::detachInterface(), edgeCollapser::determineDuplicatePointsOnFace(), triSurfaceTools::edgeCosAngle(), meshOctreeModifier::ensureCorrectRegularity(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::erase(), Foam::help::exchangeMap(), polyMeshFilter::filter(), removeFaces::filterFace(), surfaceMorpherCells::findBoundaryVertices(), immersedBoundaryFvPatch::findCellCells(), meshOctreeCube::findContainedEdges(), findCellsIntersectingSurface::findIntersectedCells(), meshSurfaceOptimizer::findInvertedVertices(), meshOctree::findNearestCorner(), boundaryLayers::findPatchesToBeTreatedTogether(), surfaceSets::getHangingCells(), triSurfaceTools::getMergedEdges(), cellDistFuncs::getPointNeighbours(), removePoints::getUnrefimentSet(), autoLayerDriver::handleNonManifolds(), surfaceInterpolateFields::interpolateFields(), topoSet::invert(), main(), immersedBoundaryFvPatch::makeIbCellCells(), immersedBoundaryFvPatch::makeIbCells(), immersedBoundaryFvPatch::makeIbInsideFaces(), immersedBoundaryFvPatch::makeIbInternalFaces(), immersedBoundaryFvPatch::makeTriAddressing(), meshSurfaceMapper::mapCorners(), meshSurfaceMapper2D::mapCorners(), fvMeshAdder::MapDimFields(), fvMeshDistribute::mapExposedFaces(), fvMeshAdder::MapSurfaceFields(), meshSurfaceMapper::mapVerticesOntoSurfacePatches(), fvMeshAdder::MapVolFields(), meshOctreeModifier::markAdditionalLayers(), meshOctreeModifier::markAdditionalLayersOfFaceNeighbours(), cellDistFuncs::maxPatchSize(), merge(), removeFaces::mergeFaces(), meshRefinement::mergePatchFacesUndo(), polyMeshAdder::mergePrimitives(), chemkinReader::molecularWeight(), meshSurfaceOptimizer::newEdgePositionLaplacian(), Foam::help::numberOfEdgeGroups(), Foam::help::numberOfFaceGroups(), InflationInjection< CloudType >::parcelsToInject(), partTetMesh::partTetMesh(), partTriMesh::partTriMesh(), boundaryMesh::patchify(), slidingInterface::projectPoints(), meshOctreeCreator::refineBoxesNearDataBoxes(), layerAdditionRemoval::removeCellLayer(), reorderMesh(), fieldAverage::resetFields(), faceAreaWeightAMI< SourcePatch, TargetPatch >::restartUncoveredSourceFace(), meshOctreeInsideOutside::reviseDataBoxes(), globalPoints::sendPatchPoints(), fvMeshSubset::setCellSubset(), patchWave::setChangedFaces(), patchDataWave< TransferType >::setChangedFaces(), motionSmootherAlgo::setDisplacementPatchFields(), MRFZone::setMRFFaces(), meshRefinement::splitFacesUndo(), topoSet::subset(), cellDistFuncs::sumPatchSize(), surfaceIntersection::surfaceIntersection(), medialAxisMeshMover::update(), setUpdater::updateSets(), polyMeshFilter::updateSets(), topoSetSource::usage(), triSurfaceTools::vertexUsesFace(), wallLayerCells::wallLayerCells(), domainDecomposition::writeDecomposition(), and writeVTK().

◆ find() [1/2]

iterator find ( const Key & )

Find and return an iterator set at the hashedEntry.

If not found iterator = end()

Referenced by meshCutAndRemove::addEdgeCutsToFace(), meshCutter::addEdgeCutsToFace(), triSurfaceMesh::addFaceToEdge(), meshRefinement::allocateInterRegionFaceZone(), meshToMesh0::calcAddressing(), globalMeshData::calcSharedEdges(), objectRegistry::checkOut(), triSurfacePartitioner::cornersSharedByEdgeGroups(), meshStructure::correct(), patchPatchDist::correct(), globalMeshData::countSharedEdges(), cyclicPolyPatch::coupledEdges(), cyclicGAMGInterface::cyclicGAMGInterface(), triSurfacePartitioner::edgeGroupsSharedByPatches(), extractPatchGroups(), surfaceIntersection::filterLabels(), fvMeshDistribute::findCouples(), polyBoundaryMesh::groupPatchIDs(), Foam::stringOps::inplaceExpand(), polyMeshAdder::insertVertices(), meshCutAndRemove::loopToFace(), meshCutter::loopToFace(), main(), PatchTools::matchEdges(), polyBoundaryMesh::neighbourEdges(), GAMGAgglomeration::New(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator==(), processorGAMGInterface::processorGAMGInterface(), vtkUnstructuredReader::read(), wallBoundedStreamLine::read(), triSurface::readOBJ(), triSurface::readTRI(), functionObjectList::remove(), DictionaryBase< DLPtrList< T >, T >::remove(), probes::sampleAndWrite(), tetDecomposer::setRefinement(), surfaceFeatures::surfaceFeatures(), and meshReader::warnDuplicates().

Here is the caller graph for this function:

◆ find() [2/2]

const_iterator find ( const Key & ) const

Find and return an const_iterator set at the hashedEntry.

If not found iterator = end()

◆ toc()

Foam::List< Key > toc ( ) const

Return the table of contents.

Definition at line 201 of file HashTable.C.

Referenced by layerAdditionRemoval::addCellLayer(), immersedBoundaryFvPatch::addIbCornerCells(), primitiveMeshGeometry::affectedCells(), polyMeshGeometry::affectedCells(), attachDetach::attachInterface(), slidingInterface::calcAttachedAddressing(), PrimitivePatch< labelledTri, List, pointField, point >::calcBdryPoints(), cellToCellStencil::calcFaceCells(), cellToFaceStencil::calcFaceCells(), surfaceFormatsCore::checkSupport(), regionToFace::combine(), vtkPV4Foam::convertVolField(), vtkPV3Foam::convertVolFields(), slidingInterface::coupleInterface(), meshRefinement::createBaffles(), autoRefineDriver::danglingCellRefine(), attachDetach::detachInterface(), immersedBoundaryFvPatch::findCellCells(), findCellsIntersectingSurface::findIntersectedCells(), faceCoupleInfo::findSlavesCoveringMaster(), dynamicIndexedOctree::findSphere(), indexedOctree< Foam::treeDataFace >::findSphere(), motionSmootherAlgo::getAffectedFacesAndPoints(), cellDistFuncs::getPointNeighbours(), removePoints::getUnrefimentSet(), triSurfaceTools::getVertexVertices(), InflationInjection< CloudType >::InflationInjection(), main(), immersedBoundaryFvPatch::makeIbCellCells(), immersedBoundaryFvPatch::makeIbCells(), immersedBoundaryFvPatch::makeIbInsideFaces(), immersedBoundaryFvPatch::makeIbInternalFaces(), immersedBoundaryFvPatch::makeTriAddressing(), Foam::MapConsistentSubMesh(), cellClassification::markCells(), merge(), objectRegistry::names(), cellToFaceStencil::unionEqOp::operator()(), cellToCellStencil::unionEqOp::operator()(), ParticleErosion< CloudType >::ParticleErosion(), PatchPostProcessing< CloudType >::PatchPostProcessing(), Foam::polyMeshZipUpCells(), slidingInterface::projectPoints(), polyMeshGenPoints::read(), polyMeshGenCells::read(), residuals::read(), polyMeshGenFaces::read(), triSurface::readTRI(), refineImmersedBoundaryMesh::refinementCells(), autoRefineDriver::refinementInterfaceRefine(), layerAdditionRemoval::removeCellLayer(), cellSetOption::setCellSet(), fvMeshSubset::setCellSubset(), hexRef8::setUnrefinement(), uniformInterpolatedDisplacementPointPatchVectorField::updateCoeffs(), meshOctreeModifier::updateCommunicationPattern(), Foam::meshTools::writeOBJ(), and polyMeshGenModifier::zipUpCells().

◆ sortedToc()

Foam::List< Key > sortedToc ( ) const

Return the table of contents as a sorted list.

Definition at line 216 of file HashTable.C.

Referenced by preservePatchesConstraint::add(), singleProcessorFaceSetsConstraint::add(), preservePatchesConstraint::apply(), edgeMeshFormatsCore::checkSupport(), autoRefineDriver::doRefine(), DispersionRASModel< CloudType >::epsilonModel(), patchProbes::findElements(), coupleGroupIdentifier::findOtherPatchID(), DispersionRASModel< CloudType >::kModel(), BrownianMotionForce< CloudType >::kModel(), main(), Foam::mergeAndWrite(), sampledPatch::patchIDs(), externalCoupledFunctionObject::read(), objectRegistry::sortedNames(), externalCoupledFunctionObject::writeGeometry(), and meshRefinement::zonify().

Here is the caller graph for this function:

◆ printInfo()

Foam::Ostream & printInfo ( Ostream & os ) const

Print information.

Definition at line 58 of file HashTableIO.C.

Referenced by main().

Here is the caller graph for this function:

◆ insert()

bool insert	(	const Key &	key,
		const T &	newElmt
	)

inline

Insert a new hashedEntry.

Definition at line 80 of file HashTableI.H.

Referenced by triSurfaceMesh::addFaceToEdge(), meshRefinement::allocateInterRegionFaceZone(), globalMeshData::calcSharedEdges(), polyMesh::checkEdgeAlignment(), primitiveMesh::checkEdgeAlignment(), objectRegistry::checkIn(), Foam::checkWedges(), meshStructure::correct(), patchPatchDist::correct(), globalMeshData::countSharedEdges(), cyclicPolyPatch::coupledEdges(), cyclicGAMGInterface::cyclicGAMGInterface(), autoRefineDriver::doRefine(), extractPatchGroups(), extractSurface(), fvMeshDistribute::findCouples(), polyBoundaryMesh::groupPatchIDs(), chemkinReader::initReactionKeywordTable(), HashSet< label, Hash< label > >::insert(), surfaceInterpolateFields::interpolateFields(), objectRegistry::lookupClass(), main(), Foam::MapConsistentSubMesh(), PatchTools::matchEdges(), edgeMesh::mergeEdges(), edgeMesh::mergePoints(), polyBoundaryMesh::neighbourEdges(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), boundaryMesh::patchify(), processorGAMGInterface::processorGAMGInterface(), functionObjectList::read(), wallBoundedStreamLine::read(), triSurface::readOBJ(), triSurface::readTRI(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::resize(), tetDecomposer::setRefinement(), surfaceFeatures::surfaceFeatures(), boundaryCutter::updateMesh(), meshCutAndRemove::updateMesh(), meshCutter::updateMesh(), wallLayerCells::wallLayerCells(), meshReader::warnDuplicates(), and meshRefinement::zonify().

Here is the caller graph for this function:

◆ set() [2/2]

bool set	(	const Key &	,
		const T &	newElmt
	)

inline

Assign a new hashedEntry, overwriting existing entries.

◆ erase() [1/5]

bool erase ( const iterator & )

Erase a hashedEntry specified by given iterator.

This invalidates the iterator until the next operator++

Referenced by topoSetSource::addOrDelete(), fieldToCell::applyToSet(), normalToFace::applyToSet(), meshOctreeAddressing::checkAndFixIrregularConnections(), objectRegistry::checkOut(), cyclicPolyPatch::coupledEdges(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::erase(), immersedBoundaryFvPatch::findCellCells(), cellDistFuncs::getPointNeighbours(), main(), polyBoundaryMesh::matchGroups(), polyBoundaryMesh::neighbourEdges(), probes::prepare(), vtkUnstructuredReader::read(), HashPtrTable< ThermoType >::remove(), perfectInterface::setRefinement(), faceCollapser::setRefinement(), and HashSet< label, Hash< label > >::unset().

Here is the caller graph for this function:

◆ erase() [2/5]

bool erase ( const Key & )

Erase a hashedEntry specified by the given key.

◆ erase() [3/5]

label erase ( const UList< Key > & )

Remove entries given by the listed keys from this HashTable.

Return the number of elements removed

◆ erase() [4/5]

label erase ( const HashTable< AnyType, Key, AnyHash > & )

Remove entries given by the given keys from this HashTable.

Return the number of elements removed. The parameter HashTable needs the same type of key, but the type of values held and the hashing function are arbitrary.

◆ resize()

void resize ( const label newSize )

Resize the hash table for efficiency.

Definition at line 436 of file HashTable.C.

Referenced by polyMesh::checkEdgeAlignment(), primitiveMesh::checkEdgeAlignment(), Foam::checkWedges(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::clearStorage(), MGridGenGAMGAgglomeration::detectSharedFaces(), fvMeshDistribute::distribute(), doCommand(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::shrink().

Here is the caller graph for this function:

◆ clear()

void clear ( )

Clear all entries from table.

Definition at line 473 of file HashTable.C.

Referenced by chemkinReader::addReaction(), decompositionMethod::calcCellCells(), cellToCellStencil::calcFaceCells(), cellToFaceStencil::calcFaceCells(), FECCellToFaceStencil::calcFaceStencil(), cellToFaceStencil::calcFaceStencil(), globalMeshData::calcSharedEdges(), isoSurfaceCell::calcSnappedPoint(), meshSurfacePartitioner::calculateCornersEdgesAndAddressing(), meshSurfaceCheckInvertedVertices::checkVertices(), HashPtrTable< ThermoType >::clear(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::clearStorage(), slidingInterface::coupleInterface(), MGridGenGAMGAgglomeration::detectSharedFaces(), edgeCollapser::determineDuplicatePointsOnFace(), doCommand(), meshOctreeModifier::ensureCorrectRegularity(), meshOptimizer::findBadFaces(), Foam::polyMeshGenChecks::findBadFaces(), Foam::polyMeshGenChecks::findBadFacesRelaxed(), checkNonMappableCellConnections::findCells(), meshOptimizer::findLowQualityFaces(), Foam::polyMeshGenChecks::findLowQualityFaces(), checkBoundaryFacesSharingTwoEdges::findPoints(), Foam::polyMeshGenChecks::findWorstQualityFaces(), triSurfaceMesh::isSurfaceClosed(), meshOctreeModifier::markAdditionalLayers(), meshOctreeModifier::markAdditionalLayersOfFaceNeighbours(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), slidingInterface::projectPoints(), wallBoundedStreamLine::read(), globalPoints::receivePatchPoints(), meshOctreeCreator::refineBoxesNearDataBoxes(), tetDecomposer::setRefinement(), autoRefineDriver::shellRefine(), meshRefinement::splitFacesUndo(), surfaceFeatures::surfaceFeatures(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::transfer(), and extendedUpwindCellToFaceStencil::transportStencil().

Here is the caller graph for this function:

◆ clearStorage()

void clearStorage ( )

Clear the table entries and the table itself.

Equivalent to clear() followed by resize(0)

Definition at line 497 of file HashTable.C.

◆ shrink()

void shrink ( )

Shrink the allocated table to approx. twice number of elements.

Definition at line 505 of file HashTable.C.

Referenced by main().

Here is the caller graph for this function:

◆ transfer()

void transfer ( HashTable< T, Key, Hash > & ht )

Transfer the contents of the argument table into this table.

and annul the argument table.

Definition at line 518 of file HashTable.C.

Referenced by primitiveMesh::checkEdgeLength(), findCellsIntersectingSurface::findIntersectedCells(), meshOctreeAddressing::findUsedBoxes(), polyBoundaryMesh::matchGroups(), polyTopoChange::renumber(), motionSmootherAlgo::scaleMesh(), extendedEdgeMesh::transfer(), and updateCellSet().

Here is the caller graph for this function:

◆ xfer()

Foam::Xfer< Foam::HashTable< T, Key, Hash > > xfer ( )

inline

Transfer contents to the Xfer container.

Definition at line 102 of file HashTableI.H.

◆ operator[]() [1/2]

T& operator[] ( const Key & )

inline

Find and return a hashedEntry.

◆ operator[]() [2/2]

const T& operator[] ( const Key & ) const

inline

Find and return a hashedEntry.

◆ operator()()

T & operator() ( const Key & key )

inline

Find and return a hashedEntry, create it null if not present.

Definition at line 143 of file HashTableI.H.

◆ operator=()

void operator= ( const HashTable< T, Key, Hash > & rhs )

Assignment.

Definition at line 542 of file HashTable.C.

◆ operator==()

bool operator== ( const HashTable< T, Key, Hash > & rhs ) const

Equality. Hash tables are equal if the keys and values are equal.

Independent of table storage size and table order.

Definition at line 573 of file HashTable.C.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator!=().

Here is the caller graph for this function:

◆ operator!=()

bool operator!= ( const HashTable< T, Key, Hash > & rhs ) const

The opposite of the equality operation. Takes linear time.

Definition at line 599 of file HashTable.C.

◆ begin() [1/2]

Foam::HashTable< T, Key, Hash >::iterator begin ( )

inline

Iterator set to the beginning of the HashTable.

Definition at line 417 of file HashTableI.H.

Referenced by meshOctreeAddressing::checkAndFixIrregularConnections(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::erase(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::filmModel(), polyBoundaryMesh::matchGroups(), filmPyrolysisRadiativeCoupledMixedFvPatchScalarField::pyrModel(), and triSurface::readOBJ().

Here is the caller graph for this function:

◆ cbegin()

Foam::HashTable< T, Key, Hash >::const_iterator cbegin ( ) const

inline

const_iterator set to the beginning of the HashTable

Definition at line 512 of file HashTableI.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::begin(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator==(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::resize().

Here is the caller graph for this function:

◆ begin() [2/2]

Foam::HashTable< T, Key, Hash >::const_iterator begin ( ) const

inline

const_iterator set to the beginning of the HashTable

Definition at line 520 of file HashTableI.H.

◆ erase() [5/5]

Foam::label erase ( const HashTable< AnyType, Key, AnyHash > & rhs )

Definition at line 415 of file HashTable.C.

Friends And Related Function Documentation

◆ HashPtrTable

friend class HashPtrTable

friend

Declare friendship with the HashPtrTable class.

Definition at line 179 of file HashTable.H.

◆ iteratorBase

friend class iteratorBase

friend

Declare friendship with the iteratorBase.

Definition at line 186 of file HashTable.H.

◆ iterator

friend class iterator

friend

Declare friendship with the iterator.

Definition at line 189 of file HashTable.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::begin(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::erase().

◆ const_iterator

friend class const_iterator

friend

Declare friendship with the const_iterator.

Definition at line 192 of file HashTable.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::cbegin(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator==(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::resize().

◆ operator>>

Istream& operator>>	(	Istream &	,
		HashTable< T, Key, Hash > &
	)

friend

◆ operator

Ostream& operator	(	Ostream &	,
		const HashTable< T, Key, Hash > &
	)

friend

Field Documentation

◆ const_reference

const typedef T& const_reference

Type that can be used for storing into constant.

HashTable::value_type objects. This type is usually const HashTable::value_type&.

Definition at line 330 of file HashTable.H.

◆ nElmts_

label nElmts_

private

The current number of elements in table.

Definition at line 152 of file HashTable.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::clear(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::shrink(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::transfer().

◆ tableSize_

label tableSize_

private

Number of primary entries allocated in table.

Definition at line 155 of file HashTable.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::clear(), HashTable::iteratorBase::increment(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::operator=(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::resize(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::shrink(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::transfer().

◆ table_

hashedEntry** table_

private

The table of primary entries.

Definition at line 158 of file HashTable.H.

Referenced by HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::clear(), HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::resize(), and HashTable< Foam::autoPtr< Foam::interfaceCompositionModel > >::transfer().

The documentation for this class was generated from the following files:

src/OpenFOAM/containers/HashTables/HashTable/HashTable.H
src/OpenFOAM/containers/HashTables/HashTable/HashTable.C
src/OpenFOAM/containers/HashTables/HashTable/HashTableI.H
src/OpenFOAM/containers/HashTables/HashTable/HashTableIO.C

Data Structures

Public Types

Public Member Functions

Data Fields

Private Member Functions

Static Private Member Functions

Private Attributes

Friends

Detailed Description

Member Typedef Documentation

◆ value_type

◆ reference

◆ size_type

Constructor & Destructor Documentation

◆ HashTable() [1/4]

◆ HashTable() [2/4]

◆ HashTable() [3/4]

◆ HashTable() [4/4]

◆ ~HashTable()

Member Function Documentation

◆ canonicalSize()

◆ hashKeyIndex()

◆ set() [1/2]

◆ capacity()

◆ size()

◆ empty()

◆ found()

◆ find() [1/2]

◆ find() [2/2]

◆ toc()

◆ sortedToc()

◆ printInfo()

◆ insert()

◆ set() [2/2]

◆ erase() [1/5]

◆ erase() [2/5]

◆ erase() [3/5]

◆ erase() [4/5]

◆ resize()

◆ clear()

◆ clearStorage()

◆ shrink()

◆ transfer()

◆ xfer()

◆ operator[]() [1/2]

◆ operator[]() [2/2]

◆ operator()()

◆ operator=()

◆ operator==()

◆ operator!=()

◆ begin() [1/2]

◆ cbegin()

◆ begin() [2/2]

◆ erase() [5/5]

Friends And Related Function Documentation

◆ HashPtrTable

◆ iteratorBase

◆ iterator

◆ const_iterator

◆ operator>>

◆ operator

Field Documentation

◆ const_reference

◆ nElmts_

◆ tableSize_

◆ table_
