Pre-declare SubField and related Field type. More...

Inheritance diagram for Field:

[legend]

Public Types
typedef pTraits< Type >::cmptType	cmptType
	Component type. More...

typedef SubField< Type >	subField
	Declare type of subField. More...

Public Member Functions
	Field ()
	Construct null. More...

	Field (const label)
	Construct given size. More...

	Field (const label, const Type &)
	Construct given size and initial value. More...

	Field (const UList< Type > &)
	Construct as copy of a UList<Type> More...

	Field (const Xfer< List< Type > > &)
	Construct by transferring the List contents. More...

	Field (const UList< Type > &mapF, const labelUList &mapAddressing)
	Construct by 1 to 1 mapping from the given field. More...

	Field (const tmp< Field< Type > > &tmapF, const labelUList &mapAddressing)
	Construct by 1 to 1 mapping from the given tmp field. More...

	Field (const UList< Type > &mapF, const labelListList &mapAddressing, const scalarListList &weights)
	Construct by interpolative mapping from the given field. More...

	Field (const tmp< Field< Type > > &tmapF, const labelListList &mapAddressing, const scalarListList &weights)
	Construct by interpolative mapping from the given tmp field. More...

	Field (const UList< Type > &mapF, const FieldMapper &map, const bool applyFlip=true)
	Construct by mapping from the given field. More...

	Field (const UList< Type > &mapF, const FieldMapper &map, const Type &defaultValue, const bool applyFlip=true)
	Construct by mapping from the given field. More...

	Field (const UList< Type > &mapF, const FieldMapper &map, const UList< Type > &defaultValues, const bool applyFlip=true)
	Construct by mapping from the given field. More...

	Field (const tmp< Field< Type > > &tmapF, const FieldMapper &map, const bool applyFlip=true)
	Construct by mapping from the given tmp field. More...

	Field (const tmp< Field< Type > > &tmapF, const FieldMapper &map, const Type &defaultValue, const bool applyFlip=true)
	Construct by mapping from the given tmp field. Supplied uniform. More...

	Field (const tmp< Field< Type > > &tmapF, const FieldMapper &map, const UList< Type > &defaultValues, const bool applyFlip=true)
	Construct by mapping from the given tmp field. Supplied values. More...

	Field (const Field< Type > &)
	Construct as copy. More...

	Field (Field< Type > &, bool reUse)
	Construct as copy or re-use as specified. More...

	Field (const Xfer< Field< Type > > &)
	Construct by transferring the Field contents. More...

	Field (const tmp< Field< Type > > &)
	Construct as copy of tmp<Field> More...

	Field (Istream &)
	Construct from Istream. More...

	Field (const word &keyword, const dictionary &, const label size)
	Construct from a dictionary entry. More...

tmp< Field< Type > >	clone () const
	Clone. More...

void	map (const UList< Type > &mapF, const labelUList &mapAddressing)
	1 to 1 map from the given field More...

void	map (const tmp< Field< Type > > &tmapF, const labelUList &mapAddressing)
	1 to 1 map from the given tmp field More...

void	map (const UList< Type > &mapF, const labelListList &mapAddressing, const scalarListList &weights)
	Interpolative map from the given field. More...

void	map (const tmp< Field< Type > > &tmapF, const labelListList &mapAddressing, const scalarListList &weights)
	Interpolative map from the given tmp field. More...

void	map (const UList< Type > &mapF, const FieldMapper &map, const bool applyFlip=true)
	Map from the given field. More...

void	map (const tmp< Field< Type > > &tmapF, const FieldMapper &map, const bool applyFlip=true)
	Map from the given tmp field. More...

void	autoMap (const FieldMapper &map, const bool applyFlip=true)
	Map from self. More...

void	rmap (const UList< Type > &mapF, const labelUList &mapAddressing)
	1 to 1 reverse-map from the given field More...

void	rmap (const tmp< Field< Type > > &tmapF, const labelUList &mapAddressing)
	1 to 1 reverse-map from the given tmp field More...

void	rmap (const UList< Type > &mapF, const labelUList &mapAddressing, const UList< scalar > &weights)
	Interpolative reverse map from the given field. More...

void	rmap (const tmp< Field< Type > > &tmapF, const labelUList &mapAddressing, const UList< scalar > &weights)
	Interpolative reverse map from the given tmp field. More...

void	negate ()
	Negate this field. More...

tmp< Field< cmptType > >	component (const direction) const
	Return a component field of the field. More...

void	replace (const direction, const UList< cmptType > &)
	Replace a component field of the field. More...

void	replace (const direction, const tmp< Field< cmptType > > &)
	Replace a component field of the field. More...

void	replace (const direction, const cmptType &)
	Replace a component field of the field. More...

tmp< Field< Type > >	T () const
	Return the field transpose (only defined for second rank tensors) More...

void	writeEntry (const word &keyword, Ostream &os) const
	Write the field as a dictionary entry. More...

void	operator= (const Field< Type > &)

void	operator= (const UList< Type > &)

void	operator= (const SubField< Type > &)

void	operator= (const tmp< Field< Type > > &)

void	operator= (const Type &)

template<class Form , class Cmpt , int nCmpt>
void	operator= (const VectorSpace< Form, Cmpt, nCmpt > &)

void	operator+= (const UList< Type > &)

void	operator+= (const tmp< Field< Type > > &)

void	operator-= (const UList< Type > &)

void	operator-= (const tmp< Field< Type > > &)

void	operator*= (const UList< scalar > &)

void	operator*= (const tmp< Field< scalar > > &)

void	operator/= (const UList< scalar > &)

void	operator/= (const tmp< Field< scalar > > &)

void	operator+= (const Type &)

void	operator-= (const Type &)

void	operator*= (const scalar &)

void	operator/= (const scalar &)

template<class Type >
void	operator= (const Field< Type > &rhs)

template<class Type >
void	operator= (const SubField< Type > &rhs)

template<class Type >
void	operator= (const UList< Type > &rhs)

template<class Type >
void	operator= (const tmp< Field > &rhs)

template<class Type >
void	operator= (const Type &t)

Static Public Member Functions
static const Field< Type > &	null ()
	Return a null field. More...

template<class Type2 >
static tmp< Field< Type > >	NewCalculatedType (const Field< Type2 > &f)
	Return a pointer to a new calculatedFvPatchFieldField created on. More...

Static Public Attributes
static const char *const	typeName

Friends
Ostream &	operator (Ostream &, const Field< Type > &)

Ostream &	operator (Ostream &, const tmp< Field< Type > > &)

Detailed Description

Pre-declare SubField and related Field type.

Generic templated field type.

Source files

Definition at line 57 of file Field.H.

Member Typedef Documentation

◆ cmptType

typedef pTraits<Type>::cmptType cmptType

Component type.

Definition at line 86 of file Field.H.

◆ subField

typedef SubField<Type> subField

Declare type of subField.

Definition at line 89 of file Field.H.

Constructor & Destructor Documentation

◆ Field() [1/21]

Field ( )

Construct null.

Used for temporary fields which are initialised after construction

Definition at line 42 of file Field.C.

◆ Field() [2/21]

Field ( const label )

explicit

Construct given size.

Used for temporary fields which are initialised after construction

◆ Field() [3/21]

Field	(	const	label,
		const Type &
	)

Construct given size and initial value.

◆ Field() [4/21]

Field ( const UList< Type > & )

explicit

Construct as copy of a UList<Type>

◆ Field() [5/21]

Field ( const Xfer< List< Type > > & )

explicit

Construct by transferring the List contents.

◆ Field() [6/21]

Field	(	const UList< Type > &	mapF,
		const labelUList &	mapAddressing
	)

Construct by 1 to 1 mapping from the given field.

Definition at line 64 of file Field.C.

◆ Field() [7/21]

Field	(	const tmp< Field< Type > > &	tmapF,
		const labelUList &	mapAddressing
	)

Construct by 1 to 1 mapping from the given tmp field.

Definition at line 77 of file Field.C.

◆ Field() [8/21]

Field	(	const UList< Type > &	mapF,
		const labelListList &	mapAddressing,
		const scalarListList &	weights
	)

Construct by interpolative mapping from the given field.

◆ Field() [9/21]

Field	(	const tmp< Field< Type > > &	tmapF,
		const labelListList &	mapAddressing,
		const scalarListList &	weights
	)

Construct by interpolative mapping from the given tmp field.

◆ Field() [10/21]

Field	(	const UList< Type > &	mapF,
		const FieldMapper &	map,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given field.

◆ Field() [11/21]

Field	(	const UList< Type > &	mapF,
		const FieldMapper &	map,
		const Type &	defaultValue,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given field.

◆ Field() [12/21]

Field	(	const UList< Type > &	mapF,
		const FieldMapper &	map,
		const UList< Type > &	defaultValues,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given field.

◆ Field() [13/21]

Field	(	const tmp< Field< Type > > &	tmapF,
		const FieldMapper &	map,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given tmp field.

◆ Field() [14/21]

Field	(	const tmp< Field< Type > > &	tmapF,
		const FieldMapper &	map,
		const Type &	defaultValue,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given tmp field. Supplied uniform.

value for unmapped items

◆ Field() [15/21]

Field	(	const tmp< Field< Type > > &	tmapF,
		const FieldMapper &	map,
		const UList< Type > &	defaultValues,
		const bool	applyFlip = `true`
	)

Construct by mapping from the given tmp field. Supplied values.

for unmapped items

◆ Field() [16/21]

Field ( const Field< Type > & )

Construct as copy.

◆ Field() [17/21]

Field	(	Field< Type > &	,
		bool	reUse
	)

Construct as copy or re-use as specified.

◆ Field() [18/21]

Field ( const Xfer< Field< Type > > & )

Construct by transferring the Field contents.

◆ Field() [19/21]

Field ( const tmp< Field< Type > > & )

Construct as copy of tmp<Field>

◆ Field() [20/21]

Field ( Istream & )

Construct from Istream.

◆ Field() [21/21]

Field	(	const word &	keyword,
		const dictionary &	,
		const label	size
	)

Construct from a dictionary entry.

Member Function Documentation

◆ null()

static const Field<Type>& null ( )

inlinestatic

Return a null field.

Definition at line 100 of file Field.H.

Referenced by slicedFvPatchField< Type >::gradientBoundaryCoeffs(), slicedFvPatchField< Type >::gradientInternalCoeffs(), slicedFvPatchField< Type >::patchInternalField(), slicedFvPatchField< Type >::patchNeighbourField(), slicedFvPatchField< Type >::snGrad(), slicedFvPatchField< Type >::valueBoundaryCoeffs(), and slicedFvPatchField< Type >::valueInternalCoeffs().

Here is the caller graph for this function:

◆ clone()

Foam::tmp< Foam::Field< Type > > clone ( ) const

Clone.

Definition at line 335 of file Field.C.

◆ NewCalculatedType()

static tmp<Field<Type> > NewCalculatedType ( const Field< Type2 > & f )

inlinestatic

Return a pointer to a new calculatedFvPatchFieldField created on.

freestore without setting patchField values

Definition at line 235 of file Field.H.

◆ map() [1/6]

void map	(	const UList< Type > &	mapF,
		const labelUList &	mapAddressing
	)

1 to 1 map from the given field

Definition at line 345 of file Field.C.

Referenced by sampledPatchInternalField::sampleField(), and polyMesh::updateMesh().

Here is the caller graph for this function:

◆ map() [2/6]

void map	(	const tmp< Field< Type > > &	tmapF,
		const labelUList &	mapAddressing
	)

1 to 1 map from the given tmp field

Definition at line 374 of file Field.C.

◆ map() [3/6]

void map	(	const UList< Type > &	mapF,
		const labelListList &	mapAddressing,
		const scalarListList &	weights
	)

Interpolative map from the given field.

◆ map() [4/6]

void map	(	const tmp< Field< Type > > &	tmapF,
		const labelListList &	mapAddressing,
		const scalarListList &	weights
	)

Interpolative map from the given tmp field.

◆ map() [5/6]

void map	(	const UList< Type > &	mapF,
		const FieldMapper &	map,
		const bool	applyFlip = `true`
	)

Map from the given field.

◆ map() [6/6]

void map	(	const tmp< Field< Type > > &	tmapF,
		const FieldMapper &	map,
		const bool	applyFlip = `true`
	)

Map from the given tmp field.

◆ autoMap()

void autoMap	(	const FieldMapper &	map,
		const bool	applyFlip = `true`
	)

Map from self.

Definition at line 508 of file Field.C.

Referenced by wallHeatTransferFvPatchScalarField::autoMap(), atmBoundaryLayer::autoMap(), fvPatchField< Type >::autoMap(), MapInternalField< Type, MeshMapper, surfaceMesh >::operator()(), MapInternalField< Type, MeshMapper, volMesh >::operator()(), and MapInternalField< Type, MeshMapper, pointMesh >::operator()().

Here is the caller graph for this function:

◆ rmap() [1/4]

void rmap	(	const UList< Type > &	mapF,
		const labelUList &	mapAddressing
	)

1 to 1 reverse-map from the given field

Definition at line 571 of file Field.C.

Referenced by extendedEdgeMesh::add(), extendedEdgeMesh::flipNormals(), fvMeshAdder::MapSurfaceField(), fvMeshAdder::MapVolField(), and fvPatchField< Type >::rmap().

Here is the caller graph for this function:

◆ rmap() [2/4]

void rmap	(	const tmp< Field< Type > > &	tmapF,
		const labelUList &	mapAddressing
	)

1 to 1 reverse-map from the given tmp field

Definition at line 592 of file Field.C.

◆ rmap() [3/4]

void rmap	(	const UList< Type > &	mapF,
		const labelUList &	mapAddressing,
		const UList< scalar > &	weights
	)

Interpolative reverse map from the given field.

◆ rmap() [4/4]

void rmap	(	const tmp< Field< Type > > &	tmapF,
		const labelUList &	mapAddressing,
		const UList< scalar > &	weights
	)

Interpolative reverse map from the given tmp field.

◆ negate()

void negate ( )

Negate this field.

Definition at line 635 of file Field.C.

Referenced by fvMatrix< Type >::H().

Here is the caller graph for this function:

◆ component()

Foam::tmp< Foam::Field< typename Foam::Field< Type >::cmptType > > component ( const direction d ) const

Return a component field of the field.

Definition at line 644 of file Field.C.

Referenced by Foam::ComplexField(), simpleGeomDecomp::decomposeOneProc(), cylindricalCS::globalToLocal(), Foam::Im(), Foam::ImComplexField(), cylindricalCS::localToGlobal(), main(), faceSource::processSameTypeValues(), Foam::Re(), Foam::ReComplexField(), Foam::ReImSum(), fvMatrix< Type >::residual(), basicSymmetryFvPatchField< Type >::snGradTransformDiag(), fixedNormalSlipFvPatchField< Type >::snGradTransformDiag(), partialSlipFvPatchField< Type >::snGradTransformDiag(), fvMatrix< Type >::solveSegregated(), componentDisplacementMotionSolver::updateMesh(), Foam::writeCellGraph(), and ensightPart::writeField().

Here is the caller graph for this function:

◆ replace() [1/3]

void replace	(	const	direction,
		const UList< cmptType > &
	)

Replace a component field of the field.

Referenced by fvMatrix< Type >::flux(), cylindricalCS::globalToLocal(), fvMatrix< Type >::H(), cylindricalCS::localToGlobal(), main(), externalCoupledFunctionObject::readData(), fvMatrix< Type >::residual(), and dynamicInkJetFvMesh::update().

Here is the caller graph for this function:

◆ replace() [2/3]

void replace	(	const	direction,
		const tmp< Field< cmptType > > &
	)

Replace a component field of the field.

◆ replace() [3/3]

void replace	(	const	direction,
		const cmptType &
	)

Replace a component field of the field.

◆ T()

Foam::tmp< Foam::Field< Type > > T ( ) const

Return the field transpose (only defined for second rank tensors)

Definition at line 691 of file Field.C.

Referenced by noiseFFT::noiseFFT(), filmPyrolysisTemperatureCoupledFvPatchScalarField::updateCoeffs(), and energyRegionCoupledFvPatchScalarField::updateInterfaceMatrix().

Here is the caller graph for this function:

◆ writeEntry()

void writeEntry	(	const word &	keyword,
		Ostream &	os
	)		const

Write the field as a dictionary entry.

Definition at line 700 of file Field.C.

Referenced by codedFixedValueFvPatchField< Type >::redirectPatchField(), codedFixedValuePointPatchField< Type >::redirectPatchField(), wallHeatFluxFvPatchScalarField::write(), alphatPhaseChangeWallFunctionFvPatchScalarField::write(), oscillatingVelocityPointPatchVectorField::write(), sixDoFRigidBodyDisplacementPointPatchVectorField::write(), boundaryRadiationPropertiesFvPatchField::write(), nutkRoughWallFunctionFvPatchScalarField::write(), wallHeatTransferFvPatchScalarField::write(), nutkAtmRoughWallFunctionFvPatchScalarField::write(), turbulentHeatFluxTemperatureFvPatchScalarField::write(), and atmBoundaryLayer::write().

Here is the caller graph for this function:

◆ operator=() [1/11]

void operator= ( const Field< Type > & )

Referenced by atmBoundaryLayerInletEpsilonFvPatchScalarField::atmBoundaryLayerInletEpsilonFvPatchScalarField(), atmBoundaryLayerInletKFvPatchScalarField::atmBoundaryLayerInletKFvPatchScalarField(), atmBoundaryLayerInletVelocityFvPatchVectorField::atmBoundaryLayerInletVelocityFvPatchVectorField(), oscillatingDisplacementPointPatchVectorField::updateCoeffs(), movingWallVelocityFvPatchVectorField::updateCoeffs(), translatingWallVelocityFvPatchVectorField::updateCoeffs(), and rotatingWallVelocityFvPatchVectorField::updateCoeffs().

Here is the caller graph for this function:

◆ operator=() [2/11]

void operator= ( const UList< Type > & )

◆ operator=() [3/11]

void operator= ( const SubField< Type > & )

◆ operator=() [4/11]

void operator= ( const tmp< Field< Type > > & )

◆ operator=() [5/11]

void operator= ( const Type & )

◆ operator=() [6/11]

void operator= ( const VectorSpace< Form, Cmpt, nCmpt > & vs )

Definition at line 791 of file Field.C.

◆ operator+=() [1/3]

void operator+= ( const UList< Type > & )

◆ operator+=() [2/3]

void operator+= ( const tmp< Field< Type > > & )

◆ operator-=() [1/3]

void operator-= ( const UList< Type > & )

◆ operator-=() [2/3]

void operator-= ( const tmp< Field< Type > > & )

◆ operator*=() [1/3]

void operator*= ( const UList< scalar > & )

◆ operator*=() [2/3]

void operator*= ( const tmp< Field< scalar > > & )

◆ operator/=() [1/3]

void operator/= ( const UList< scalar > & )

◆ operator/=() [2/3]

void operator/= ( const tmp< Field< scalar > > & )

◆ operator+=() [3/3]

void operator+= ( const Type & )

◆ operator-=() [3/3]

void operator-= ( const Type & )

◆ operator*=() [3/3]

void operator*= ( const scalar & )

◆ operator/=() [3/3]

void operator/= ( const scalar & )

◆ operator=() [7/11]

void operator= ( const Field< Type > & rhs )

Definition at line 738 of file Field.C.

◆ operator=() [8/11]

void operator= ( const SubField< Type > & rhs )

Definition at line 752 of file Field.C.

◆ operator=() [9/11]

void operator= ( const UList< Type > & rhs )

Definition at line 759 of file Field.C.

◆ operator=() [10/11]

void operator= ( const tmp< Field > & rhs )

Definition at line 766 of file Field.C.

◆ operator=() [11/11]

void operator= ( const Type & t )

Definition at line 783 of file Field.C.

Friends And Related Function Documentation

◆ operator [1/2]

Ostream& operator	(	Ostream &	,
		const Field< Type > &
	)

friend

Referenced by meshSurfaceEngine::calculateFaceCentres(), meshSurfaceEngine::calculateFaceNormals(), energyRegionCoupledFvPatchScalarField::evaluate(), angularOscillatingDisplacementPointPatchVectorField::updateCoeffs(), and angularOscillatingVelocityPointPatchVectorField::updateCoeffs().

◆ operator [2/2]

Ostream& operator	(	Ostream &	,
		const tmp< Field< Type > > &
	)

friend

Field Documentation

◆ typeName

const char *const typeName

static

Definition at line 94 of file Field.H.

The documentation for this class was generated from the following files:

src/OpenFOAM/fields/Fields/Field/Field.H
src/OpenFOAM/fields/Fields/Field/Field.C

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Friends

Detailed Description

Member Typedef Documentation

◆ cmptType

◆ subField

Constructor & Destructor Documentation

◆ Field() [1/21]

◆ Field() [2/21]

◆ Field() [3/21]

◆ Field() [4/21]

◆ Field() [5/21]

◆ Field() [6/21]

◆ Field() [7/21]

◆ Field() [8/21]

◆ Field() [9/21]

◆ Field() [10/21]

◆ Field() [11/21]

◆ Field() [12/21]

◆ Field() [13/21]

◆ Field() [14/21]

◆ Field() [15/21]

◆ Field() [16/21]

◆ Field() [17/21]

◆ Field() [18/21]

◆ Field() [19/21]

◆ Field() [20/21]

◆ Field() [21/21]

Member Function Documentation

◆ null()

◆ clone()

◆ NewCalculatedType()

◆ map() [1/6]

◆ map() [2/6]

◆ map() [3/6]

◆ map() [4/6]

◆ map() [5/6]

◆ map() [6/6]

◆ autoMap()

◆ rmap() [1/4]

◆ rmap() [2/4]

◆ rmap() [3/4]

◆ rmap() [4/4]

◆ negate()

◆ component()

◆ replace() [1/3]

◆ replace() [2/3]

◆ replace() [3/3]

◆ T()

◆ writeEntry()

◆ operator=() [1/11]

◆ operator=() [2/11]

◆ operator=() [3/11]

◆ operator=() [4/11]

◆ operator=() [5/11]

◆ operator=() [6/11]

◆ operator+=() [1/3]

◆ operator+=() [2/3]

◆ operator-=() [1/3]

◆ operator-=() [2/3]

◆ operator*=() [1/3]

◆ operator*=() [2/3]

◆ operator/=() [1/3]

◆ operator/=() [2/3]

◆ operator+=() [3/3]

◆ operator-=() [3/3]

◆ operator*=() [3/3]

◆ operator/=() [3/3]

◆ operator=() [7/11]

◆ operator=() [8/11]

◆ operator=() [9/11]

◆ operator=() [10/11]

◆ operator=() [11/11]

Friends And Related Function Documentation

◆ operator [1/2]

◆ operator [2/2]

Field Documentation
